ASSEMBLY AND INSTALLATION

INSTRUCTIONS

Hardware Package (included):

Mounting Screw (B)Wire Connector (C)

Bolt Nut (D)

Crossbar Unit (A)

OW39573

WARNING: Turn off the main power at circuit breaker before installing fixture.

AVERTISSEMENT: Coupez la source d’alimentation principale au panneau

central de disjoncteurs avant d’installer le luminaire.

NOTE: 1. Before installing, consult local electrical codes for wiring and grounding requirements.

2.Read

and save these instructions.

1.Unscrew the two bolt nuts (D), remove the two rubber pads (E) and the crossbar unit (A) from the backplate.

2.Slip the cap set and one end of the iron through the threaded pipe and secure them with the finial, then secure the other

end of the iron to the backplate by using the set screw and lock nut.

Turn off the power at fuse or circuit box

Installation Steps

Rubber Pad (E)

Wire Connector (C)

House Ground Wire

Outlet Box

Mounting Screw (B)

Green Ground Screw

Headless Screw

Crossbar Unit (A)

Fixture Wire

Fixture Ground Wire

Backplate

Bolt Nut (D)

Rubber Pad (E)

Fixture

Finial

Set Screw

Iron

Threaded Pipe

Lock Nut

Max. 60W Type A Bulb

(not included)
