ASSEMBLY AND INSTALLATION
INSTRUCTIONS
T0724
T
Hardware Package (included):
Anchor (A)
Drywall Screw (B)
1. Unscrew the two set screws, remove the fixture from the backplate.
2. Place the fixture on the chosen surface as shown and mark the position of the 3 holes. Use an electrical
drill (not included) to drill three holes into the mounting surface. Insert the archors (A) in the holes.
If mounting to a wooden surface, drill three 3/32 in. holes into the mounting surface. Install the three drywall
screws (B), through the backplate and into the mounting surface.
If mounting to wall board or brick, drill three 7/32 in. holes into the mounting surface. Insert the wall anchors (A)
and attach the mounting plate using the three drywall screws (B).
3. Fasten the backplate onto the wall with three drywall screws (B).
4. Attach the backplate of the fixture to the mounting surface by inserting set screws。
Important to Know
For best results, position the solar panel in a location where it will receive maximum sunlight. Ideally,
the location should be free from cover or shade.
Installation Steps
Anchor (A)
Mounting Surface
Backplate
Drywall Screw (B)
Fixture
Set Screw
x
x
x
