1 947586

ISSUE 1

VIP-851-25-IC & VIP-851-70/100-IC

InformaCast® Compliant

IP/SIP 20W Amplifier 25/70/100V

INTRODUCTION

The VIP-851-25-IC and VIP-851-70/100-IC

InformaCast Compliant IP/SIP 20W Amplifiers

enable voice access to a single zone of one-way

paging over an IP network, allowing page zones to

be extended anywhere network connectivity is

available. The amplifiers can optionally be

programmed as a SIP (Session Initiation Protocol)

device for connectivity to virtually any VOIP (Voice

over IP) telephone system.

The VIP-851-25-IC has output connections for line

level and 25-volt speakers only.

The VIP-851-70/100-IC has output connections for

line level and 25-volt, 70-volt or 100-volt speakers.

SPECIFICATIONS

Features

1 Audio Input

2 Audio Outputs (VIP-851-25-IC)

4 Audio Outputs (VIP-851-25/70/100-IC)

1 Form C Relay

1 Contact Closure Input

1 SIP identity for registering to a VoIP telephone

system

Power over Ethernet 802.3at (PoE+) compatible

Front panel activity LED

Front panel PoE+ Fault indicator

Front panel Supervision Fault indicator

Provides line level audio for up to 40 Valcom

one-way amplified speaker assemblies

Contact closure or VOX operation of audio input

Removable screw terminal connectors provided

for audio and relay interfaces

AUX input music mutes during page

Barrel jack for optional DC power

Environment

Temperature: 0 to +40° C

Humidity: 0 to 85% non-precipitating

VIP-851-25-IC

VIP-851-70/100-IC

Dimensions/Weight

1 Standard 19” Rack unit

1.75” H x 16.6" W x 4.8" D

(4.4cm H x 42.2cm W x 12.2cm D)

Weight:

VIP-851-25 -IC 2.00 lbs. (0.91 kg)

VIP-851-70/100-IC 3.10 lbs. (1.41 kg)

Nominal Specifications

AUX Input Impedance: 600 Ohms

AUX Input Level: -10dBm nominal

25V or 70/100V Output 20 Watts Max.

Line Level Output Impedance: 50 Ohms

Line level Output Level: - 10dBm nominal

Relay Current: 1 Amp @ 24VDC

Nominal Power Requirements

Via rear panel barrel connector:

Voltage: 24VDC

Current: 900mA

Via 802.3at PoE+ Ethernet Switch:

802.3at: Class 4

These products are intended for use with a UL

Listed power source marked “Class 2” or “LPS”

rated 24VDC, or 48VDC (PoE).

PoE and all interconnected ITE are intended for

intra-building

.
