1 9471000

ISSUE 1

ezIP DOORPHONE / INTERCOM

EZ-DIBR

INTRODUCTION

The EZ-DIBR IP Talkback DoorPhone / Intercom

allows communication to Valcom ezIP Page

Controllers, ezIP Interactive Consoles and SIP

based telephone systems via an IP-based

network.

SPECIFICATIONS

Access Methods

•SIP – enabled telephone system

•ezIP Page Controller

•ezIP Interactive Console

•Valcom ezIP Multicast Page Group

Features

•Vandal-resistant stainless steel faceplate

•1 Form C relay

•Network activity LEDs

•Power over Ethernet (PoE) 802.3af

compatible

•Upgradable to full Valcom VIP speaker

functionality

Dimensions/Weight:

EZ-DIBR

•4.5” H x 4.5" W x 1.75" D

(11.43cm H x 11.43cm W x 4.45cm D)

•Weight: 1.68 lbs. (0.76 kg)

Network Interface

•1.62” H x 5.63” W x 3.45” D

(4.11 cm) x (14.30 cm) x (8.73 cm)

with brackets– 8.22” W (20.87 cm)

•Weight: 2.10 lbs. (0.95 kg)

EZ-DIBR Network Interface

Nominal Specifications

Input Impedance: 600 Ohms

Input Level: -10dBm

Output Impedance: 600 Ohms

Output Level: -10dBm nominal

Relay Current: 1 AMP @ 24VDC

Nominal Power Requirements

Via 802.3af PoE Ethernet Switch: Class 3

Environment

Network Interface:

Temperature: 0 to +40° C

Humidity: 0 to 85% non-precipitating

Indoor installation only

EZ-DIBR Speaker Door plate:

Suitable for indoor or outdoor installation
