PAGE 1 OF 60221 IH-9345

POWER PLUS DRUM FAN

1-800-295-5510

uline.com

H-9345, H-9346

H-9347

SPECIFICATIONS

WARNING

MAINTENANCE

• Unit includes 110-120 Volt A/C polarized-grounded

plug with 15' supply cord.

• Do not remove grounding conductor from plug or

use with an extension cord.

• To reduce risk of fire or electric shock, do not use

with any solid state speed control device. Drum

fan is equipped with an automatic reset overload

device. Unit may start unexpectedly.

• Do not put any object through the grilles into the

blade or motor.

• Unit is designed for indoor use only. Do not expose

to the elements or allow to become wet.

• Do not use to exhaust hazardous chemicals or

vapors.

• Unplug unit for storage when not in use or when

moving locations.

Always unplug or disconnect the fan from the

power supply before servicing.

Do not remove front and rear grills at the

same time. Doing so may result in difficulty

reinstalling them.

The following steps describe grill removal process in

order to access fan part for maintenance.

1. With fan turned off and

unplugged, coil the

cord and locate close

to user.

2. Using T25 Torx

screwdriver, loosen, then

remove all of the grill

fasteners on front and

rear grills. (See Figure 1)

NOTE: For front grills, skip to Step 8.

3. For rear grills, remove ground wires with a 11/32"

wrench and Phillips head screwdriver.

(See Figures 2a and 2b)

NOTE: Grill will need to be partially removed to

complete steps 3-7. (See Figure 2c)

Figure 2a

Figure 2bFigure 2c

TOOLS NEEDED

Phillips Head

Screwdriver

T25 Torx

Screwdriver

11/32" WrenchPliers

Figure 1

Para Español, vea páginas 3-4.

Pour le français, consulter les pages 5-6.
