PAGE 1 OF 6 0321 IH-3155

MOBILE SHELVING

1-800-295-5510

uline.com

CASTER INSTALLATION

INSTRUCTIONS FOR UNIT ASSEMBLY

Shelf

Support

03

04

05

06

07

08

09

Figure 2

Figure 1

Figure 3

TO INSTALL CASTERS

NOTE: Do not install self-levelers when installing casters.

1. Make sure post is positioned as shown. (See Figure 1)

2. Engage the wheel brakes to keep casters from rolling during

assembly. Use a rubber mallet to tap caster stems into posts.

(See Figure 1)

1. Start with the lowest shelf. Snap the interlocking pieces of a

shelf support (wide end down) around the post at the lowest

groove where shelf is to be located. Slide the support up or

down until it snaps onto the groove. Add a shelf support to the

same place on the remaining posts. (See Figure 2)

NOTE: NSF requires food service applications to keep the

lowest shelf at least 6" above the floor.

2. Slide post through underside of shelf until shelf slides firmly

over supports. (See Figure 3)

TOOL NEEDED

Rubber Mallet

Para Español, vea páginas 3-4.

Pour le français, consulter les pages 5-6.

Shelf x 4

PARTS

Caster x 4Shelf Support x 16 SetsPost x 4
