Revised 6/11/18 Copyright © 2018 Trade-Wind Manufacturing, LLC Proverbs 22:29 Page 1
INSTALLATION INSTRUCTIONS &
USE & CARE GUIDE
Trade-Wind
®
VSL 400 Series Liners
For Remote/In-Line Blowers
VSL 400 Series Liner Models
Model
Width
CFM
Type of
Motor &
Blower
VSL430BF
28
3
/
8
‖
*
Remote
VSL436BF
34
3
/
8
‖
*
Remote
VSL442BF
40
3
/
8
‖
*
Remote
VSL448BF
46
3
/
8
‖
*
Remote
VSL454BF
52
3
/
8
‖
*
Remote
VSL460BF
58
3
/
8
‖
*
Remote
*These models connect to an In-Line, Roof or
Wall-Mounted Remote Blower. The blower used
determines the CFM. The Trade-Wind In-Line blowers
are either 836 CFM or 1266 CFM.
Before beginning installation, please thoroughly read and become familiar with these instructions. Installation and
service must be completed by a qualified installer. Failure to properly install this product may void the warranty.
Installer:
Please leave Installation Instructions with the range hood liner.
Owner:
Please keep Installation Instructions for local electrical inspector’s use and for future reference.
WARNINGS: Must be followed carefully to avoid personal injury.
IMPORTANT: Must be followed carefully to avoid damage or incorrect installation.
TIPS: Contain helpful information to facilitate installation.
READ AND SAVE THESE INSTRUCTIONS
WARNING! TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK, OR INJURY TO
PERSONS OBSERVE THE FOLLOWING:
a) Use this unit only in the manner intended by the manufacturer. If you have any questions, please contact the
manufacturer at the address or telephone number listed in the warranty.
b) Before servicing or cleaning unit, switch power off at service panel, lock service panel, and lock the service
disconnection means to prevent power from being switched on accidentally. When the service disconnecting
means cannot be locked, securely fasten a prominent warning device, such as a tag, to the service panel.
CAUTION
--For general ventilating use only. Do not use to exhaust hazardous or explosive materials and vapors.
WARNING – TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:
a) Never leave surface units unattended at high settings. Boilovers cause smoking and greasy spillovers that may
ignite. Heat oils slowly on low or medium settings.
