Revised 6/11/18 Copyright © 2018 Trade-Wind Manufacturing, LLC Proverbs 22:29 Page 1

INSTALLATION INSTRUCTIONS &

USE & CARE GUIDE

Trade-Wind

®

VSL 400 Series Liners

For Remote/In-Line Blowers

VSL 400 Series Liner Models

Model

Width

CFM

Type of

Motor &

Blower

VSL430BF

28

3

/

8

‖

*

Remote

VSL436BF

34

3

/

8

‖

*

Remote

VSL442BF

40

3

/

8

‖

*

Remote

VSL448BF

46

3

/

8

‖

*

Remote

VSL454BF

52

3

/

8

‖

*

Remote

VSL460BF

58

3

/

8

‖

*

Remote

*These models connect to an In-Line, Roof or

Wall-Mounted Remote Blower. The blower used

determines the CFM. The Trade-Wind In-Line blowers

are either 836 CFM or 1266 CFM.

Before beginning installation, please thoroughly read and become familiar with these instructions. Installation and

service must be completed by a qualified installer. Failure to properly install this product may void the warranty.

Installer:

Please leave Installation Instructions with the range hood liner.

Owner:

Please keep Installation Instructions for local electrical inspector’s use and for future reference.

WARNINGS: Must be followed carefully to avoid personal injury.

IMPORTANT: Must be followed carefully to avoid damage or incorrect installation.

TIPS: Contain helpful information to facilitate installation.

READ AND SAVE THESE INSTRUCTIONS

WARNING! TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK, OR INJURY TO

PERSONS OBSERVE THE FOLLOWING:

a) Use this unit only in the manner intended by the manufacturer. If you have any questions, please contact the

manufacturer at the address or telephone number listed in the warranty.

b) Before servicing or cleaning unit, switch power off at service panel, lock service panel, and lock the service

disconnection means to prevent power from being switched on accidentally. When the service disconnecting

means cannot be locked, securely fasten a prominent warning device, such as a tag, to the service panel.

CAUTION

--For general ventilating use only. Do not use to exhaust hazardous or explosive materials and vapors.

WARNING – TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:

a) Never leave surface units unattended at high settings. Boilovers cause smoking and greasy spillovers that may

ignite. Heat oils slowly on low or medium settings.
