AnIMPORTANTNOTICEattheendofthisdatasheetaddressesavailability,warranty,changes,useinsafety-criticalapplications,

intellectualpropertymattersandotherimportantdisclaimers.PRODUCTIONDATA.

MSP430F6736A

,

MSP430F6735A

,

MSP430F6734A

,

MSP430F6733A

MSP430F6731A

,

MSP430F6730A

,

MSP430F6726A

,

MSP430F6725A

MSP430F6724A,MSP430F6723A,MSP430F6721A,MSP430F6720A

SLASE46A–FEBRUARY2015–REVISEDOCTOBER2018

MSP430F673xA,MSP430F672xAMixed-SignalMicrocontrollers

1DeviceOverview

1

1.1Features

1

•LowSupply-VoltageRange:

3.6VDownto1.8V

•Ultra-LowPowerConsumption

–ActiveMode(AM):

AllSystemClocksActive

265µA/MHzat8MHz,3.0V,FlashProgram

Execution(Typical)

140µA/MHzat8MHz,3.0V,RAMProgram

Execution(Typical)

–StandbyMode(LPM3):

Real-TimeClock(RTC)WithCrystal,Watchdog,

andSupplySupervisorOperational,FullRAM

Retention,FastWakeup:

1.7µAat2.2V,2.5µAat3.0V(Typical)

–OffMode(LPM4):

FullRAMRetention,SupplySupervisor

Operational,FastWakeup:

1.6µAat3.0V(Typical)

–ShutdownRTCMode(LPM3.5):

ShutdownMode,ActiveRTCWithCrystal:

1.24µAat3.0V(Typical)

–ShutdownMode(LPM4.5):

0.78µAat3.0V(Typical)

•WakeupFromStandbyModein3µs(Typical)

•16-BitRISCArchitecture,ExtendedMemory,upto

25-MHzSystemClock

•FlexiblePower-ManagementSystem

–FullyIntegratedLDOWithProgrammable

RegulatedCoreSupplyVoltage

–SupplyVoltageSupervision,Monitoring,and

Brownout

–SystemOperationFromuptoTwoAuxiliary

PowerSupplies

•UnifiedClockSystem

–FLLControlLoopforFrequencyStabilization

–Low-PowerLow-FrequencyInternalClock

Source(VLO)

–Low-FrequencyTrimmedInternalReference

Source(REFO)

–32-kHzCrystals(XT1)

•One16-BitTimerWithThreeCapture/Compare

Registers

•Three16-BitTimersWithTwoCapture/Compare

RegistersEach

•EnhancedUniversalSerialCommunication

Interfaces(eUSCIs)

–eUSCI_A0,eUSCI_A1,andeUSCI_A2

–EnhancedUARTSupportsAutomaticBaud-

RateDetection

–IrDAEncoderandDecoder

–SynchronousSPI

–eUSCI_B0

–I

2

CWithMultipleSlaveAddressing

–SynchronousSPI

•Password-ProtectedRTCWithCrystalOffset

CalibrationandTemperatureCompensation

•SeparateVoltageSupplyforBackupSubsystem

–32-kHzLow-FrequencyOscillator(XT1)

–Real-TimeClock

–BackupMemory(4×16Bits)

•Three24-BitSigma-DeltaAnalog-to-Digital

Converters(ADCs)WithDifferentialPGAInputs

•IntegratedLCDDriverWithContrastControlforup

to320Segmentsin8-MuxMode

•HardwareMultiplierSupports32-BitOperations

•10-Bit200-kspsADC

–InternalReference

–Sample-and-Hold,AutoscanFeature

–UptoSixExternalChannelsandTwoInternal

Channels,IncludingTemperatureSensor

•Three-ChannelInternalDMA

•SerialOnboardProgramming,NoExternal

ProgrammingVoltageNeeded

•DeviceComparisonSummarizestheAvailable

FamilyMembers

•Availablein100-Pinand80-PinLQFPPackages

•Single-PhaseElectronicWatt-HourMeter

DevelopmentTool(AlsoSeeToolsandSoftware)

–EVM430-F6736-MSP430F6736EVMfor

Metering

–EnergyMeasurementDesignCenterfor

MSP430™MCUs
