LP8861-Q1Low-EMIAutomotiveLEDDriverWithFour100-mAChannels

1

1Features

1

•QualifiedforAutomotiveApplications

•AECQ100QualifiedWiththeFollowingResults:

–DeviceTemperatureGrade1:–40°Cto

+125°CAmbientOperatingTemperature

•InputVoltageOperatingRange4.5Vto40V

•FourHigh-PrecisionCurrentSinks

–CurrentMatching1%(Typical)

–LEDStringCurrentupto100mA/Channel

–DimmingRatioof10000:1at100Hz

•IntegratedBoost/SEPICConverterforLEDString

Power

–OutputVoltageupto45V

–SwitchingFrequency300kHzto2.2MHz

–SwitchingSynchronizationInput

–SpreadSpectrumforLowerEMI

•Power-LineFETControlforInrushCurrent

ProtectionandStandbyEnergySaving

•ExtensiveFaultDetectionandToleranceFeatures

–FaultOutput

–InputVoltageOVP,UVLO,andOCP

–OpenandShortedLEDFaultDetection

–AutomaticLEDCurrentReductionWith

ExternalTemperatureSensor

–ThermalShutdown

•MinimumNumberofExternalComponents

2Applications

•Backlightfor:

–AutomotiveInfotainment

–AutomotiveInstrumentClusters

–SmartMirrors

–Heads-UpDisplays(HUD)

–CentralInformationDisplays(CID)

–Audio-VideoNavigation(AVN)

SystemEfficiency

3Description

TheLP8861-Q1isanautomotivehigh-efficiency,low-

EMI,easy-to-useLEDdriverwithintegrated

boost/SEPICconverter.Ithasfourhigh-precision

currentsinksthatcanprovidehighdimmingratio

brightnesscontrolwithaPWMinputsignal.

Theboost/SEPICconverterhasadaptiveoutput

voltagecontrolbasedontheLEDcurrentsink

headroomvoltages.Thisfeatureminimizesthepower

consumptionbyadjustingthevoltagetolowest

sufficientlevelinallconditions.Theboost/SEPIC

convertersupportsspreadspectrumforswitching

frequencyandanexternalsynchronizationwith

dedicatedpin.Awide-rangeadjustablefrequency

allowstheLP8861-Q1toavoiddisturbanceforAM

radioband.

TheLP8861-Q1hasanoptiontodriveanexternalp-

FETtodisconnecttheinputsupplyfromthesystemin

theeventofafaultandreduceinrushcurrentand

standbypowerconsumption.Thedevicecanreduce

LEDcurrentbasedontemperaturemeasuredwith

externalNTCsensortoprotectLEDfromoverheating

andextendLEDlifetime.

TheinputvoltagerangefortheLP8861-Q1isfrom

4.5Vto40Vtosupportautomotivestop/startand

loaddumpcondition.TheLP8861-Q1integrates

extensivefaultdetectionandprotectionfeatures.

DeviceInformation

(1)

PARTNUMBERPACKAGEBODYSIZE(NOM)

LP8861-Q1TSSOP(20)6.50mm×4.50mm

(1)Forallavailablepackages,seetheorderableaddendumat

theendofthedatasheet.

SimplifiedSchematic
