V
CC
OUT
IN−
IN+
−
+
IN−
IN+
OUT
Product
Folder
Order
Now
Technical
Documents
Tools &
Software
Support &
Community
AnIMPORTANTNOTICEattheendofthisdatasheetaddressesavailability,warranty,changes,useinsafety-criticalapplications,
intellectualpropertymattersandotherimportantdisclaimers.PRODUCTIONDATA.
LP358
,
LP2904
SLOS475A–AUGUST2005–REVISEDMAY2017
Ultra-LowPowerDualOperationalAmplifiers
1
1Features
1
•LowSupplyCurrent:54μA(Typical)
•LowOffsetVoltage:2mV(Typical)
•LowInputBiasCurrent:2nA(Typical)
•InputCommon-ModetoGND
•WideSupplyVoltage:3V<V
CC
<32V
•PinCompatibleWithLM358andLM2904
2Applications
•LCDDisplays
•PortableInstrumentation
•SensorandMeteringEquipment
•ConsumerElectronics(MP3Players,Toys)
•PowerSupplies
3Description
TheLP358andLP2904devicesareduallow-power
operationalamplifiersespeciallysuitedforbattery-
operatedapplications.Goodinputspecificationsand
widesupply-voltagerangestillareachieveddespite
theultra-lowsupplycurrent.Single-supplyoperation
isachievedwithaninputcommon-moderangethat
includesGND.
TheLP358andLP2904devicesareidealin
applicationswherewidesupplyvoltagesandlow
poweraremoreimportantthanspeedandbandwidth.
Theseapplicationsincludeportableinstrumentation,
LCDdisplays,consumerelectronics(MP3players,
toys,andsoforth),andpowersupplies.
DeviceInformation
(1)
PARTNUMBERPACKAGEBODYSIZE(NOM)
LP2904
SOIC(8)4.90×3.91
LP358
(1)Forallavailablepackages,seetheorderableaddendumat
theendofthedatasheet.
Symbol(EachAmplifier)Schematic(EachAmplifier)
