LMV331-N

,

LMV339-N

,

LMV393-N

SNOS018H–AUGUST1999–REVISEDDECEMBER2014

LMV33x-N/LMV393-NGeneral-Purpose,Low-Voltage,TinyPackComparators

TheLMV393-Nisavailablein8-pinSOICand

1Features

VSSOPpackages.TheLMV339-Nisavailablein14-

1

•(For5-VSupply,TypicalUnlessOtherwiseNoted)

pinSOICandTSSOPpackages.

•Ensured2.7-Vand5-VPerformance

TheLMV331-N/393-N/339-Nisthemostcost-

•IndustrialTemperatureRange−40°Cto85°C

effectivesolutionwherespace,lowvoltage,low

•LowSupplyCurrent60µA/Channel

power,andpricearetheprimaryspecificationin

circuitdesignforportableconsumerproducts.They

•InputCommonModeVoltageRangeIncludes

offerspecificationsthatmeetorexceedthefamiliar

Ground

LM393/339atafractionofthesupplycurrent.

•LowOutputSaturationVoltage200mV

ThechipsarebuiltwithTI'sadvancedSubmicron

•PropagationDelay200ns

Silicon-GateBiCMOSprocess.TheLMV331-N/393-

•Space-Saving5-PinSC70and5-PinSOT23

N/339-Nhavebipolarinputandoutputstagesfor

Packages

improvednoiseperformance.

2Applications

Table1.DeviceInformation

(1)

•MobileCommunications

PARTNUMBERPACKAGEBODYSIZE(NOM)

SC70(5)2.00mm×1.25mm

•NotebooksandPDAs

LMV331-N

SOT-23(5)2.90mm×1.6mm

•Battery-PoweredElectronics

SOIC(14)8.65mm×3.91mm

•General-PurposePortableDevices

LMV339-N

TSSOP(14)5.00mm×4.40mm

•General-Purpose,Low-VoltageApplications

SOIC(8)4.90mm×3.91mm

LMV393-N

VSSOP(8)3.00mm×3.00mm

3Description

TheLMV393-NandLMV339-Narelow-voltage(2.7

(1)Forallavailablepackages,seetheorderableaddendumat

theendofthedatasheet.

to5V)versionsofthedualandquadcomparators,

LM393/339,whicharespecifiedat5to30V.The

LMV331-Nisthesingleversion,whichisavailablein

space-saving,5-pinSC70and5-pinSOT23

packages.The5-pinSC70isapproximatelyhalfthe

sizeofthe5-pinSOT23.

LowSupplyCurrentFastResponseTime

1

AnIMPORTANTNOTICEattheendofthisdatasheetaddressesavailability,warranty,changes,useinsafety-criticalapplications,

intellectualpropertymattersandotherimportantdisclaimers.PRODUCTIONDATA.
