AnIMPORTANTNOTICEattheendofthisdatasheetaddressesavailability,warranty,changes,useinsafety-criticalapplications,

intellectualpropertymattersandotherimportantdisclaimers.PRODUCTIONDATA.

LMV821-N

,

LMV822-N

,

LMV822-N-Q1

,

LMV824-N

,

LMV824-N-Q1

SNOS032I–AUGUST1999–REVISEDJUNE2016

LMV82xSingle/Dual/Quad,LowVoltage,LowPower,RRO,5MHzOperationalAmplifiers

1

1Features

1

•QualifiedforAutomotiveApplications

•AEC-Q100QualifiedWiththeFollowingResults:

–LMV822-Q1AndLMV824-Q1AreAvailablein

AutomotiveAEC-Q100Grade1Version

•ForVs=5V,TypicalSupplyValuesUnless

OtherwiseNoted

•LMV824AvailableWithExtendedTemperature

Rangeto125°C

•SmallSC70-5Package2.0x1.25x0.95mm

•SpecifiedPerformanceAt2.5V,2.7Vand5V

•V

OS

3.5mV(Max)

•TCV

OS

1uV/°C

•GainBandwidthProductAt2.7V,5MHz

•I

Supply

At2.7VSupply,220μAperAmplifier

•SlewRate1.4V/µs(Min)

•CMRR90dB

•PSRR85dB

•V

CM

At5VSupply,-0.3Vto4.3V

•RailtoRailOutput(RRO)

–600ΩLoad,160mVFromRail

–10kΩLoad,55mVFromRail

•StablePerformancewithCapacitiveLoads

2Applications

•CordlessPhones

•CellularPhones

•Laptops

•PDAs

•PCMCIA

(1)Forallavailablepackages,seetheorderableaddendumat

theendofthedatasheet.

3Description

TheLMV821/LMV822/LMV824opampsbring

performanceandeconomytolowvoltage,lowpower

systems.Witha5MHzunity-gainfrequency,at2.7V

supply,anda1.4V/µsslewrate,thequiescent

currentisonly220µAperamplifier.Theyproviderail

torailoutput(RRO)swinginto600Ωload.Theinput

common-modevoltagerangeincludesgroundand

themaximuminputoffsetvoltageis3.5mV.Theyare

alsocapableofeasilydrivinglargecapacitiveloads

asindicatedintheapplicationssection.

TheLMV821singleopampisavailableinthetiny

SC70-5package,whichisabouthalfthesizeofthe

previoustitleholder,theSOT23-5.The

LMV824NDGVisspecifiedovertheextended

industrialtemperaturerangeandisinaTVSOP

package.

Overall,theLMV821/LMV822/LMV824devicesare

lowvoltage,lowpowerandperformanceopamps

designedforawiderangeofapplicationsatan

economicalprice.

DeviceInformation

(1)

DEVICENAMEPACKAGEBODYSIZE

LMV821-N

SOT23(5)2.92mmx1.60mm

SC70(5)2.00mmx1.25mm

LMV822-N

SOIC(8)4.90mmx3.91mm

VSSOP(8)3.00mmx3.00mm

LMV822-N-Q1VSSOP(8)3.00mmx3.00mm

LMV824-N

SOIC(14)8.65mmx3.91mm

TSSOP(14)5.00mmx4.40mm

LMV824-N-Q1TSSOP(14)5.00mmx4.40mm

LMV824ITVSOP(14)4.40mmx3.60mm

TelephoneLineTransceiverforPCMCIAModemCard
