AnIMPORTANTNOTICEattheendofthisdatasheetaddressesavailability,warranty,changes,useinsafety-criticalapplications,
intellectualpropertymattersandotherimportantdisclaimers.PRODUCTIONDATA.
LDC1001
SNVSBF7–NOVEMBER2019
LDC1001Inductance-to-DigitalConverter
1
1Features
1
•Magnet-freeoperation
•Sub-micronprecision
•Adjustablesensingrange(throughcoildesign)
•Lowersystemcost
•Remotesensorplacement(decouplingtheLDC
fromharshenvironments)
•Highdurability(byvirtueofcontact-lessoperation)
•Insensitivitytoenvironmentalinterference(such
asdirt,dust,water,oil)
•Supplyvoltage,analog:4.75Vto5.25V
•Supplyvoltage,I/O:1.8Vto5.25V
•Supplycurrent(withoutLCtank):1.7mA
•R
P
resolution:16bit
•Lresolution:24bit
•LCfrequencyrange:5kHzto5MHz
2Applications
•Touchbuttons
•Angularpositionsensing
•Linearpositionsensing
•Metalproximitysensing
3Description
TheLDC1001deviceisa4.75-Vto5.25-V
inductance-to-digitalconverterdesignedforparallel
resistance(Rp)andinductance(L)measurements.
Inductivesensingtechnologyenablesprecise
measurementoflinearorangularpositionofmetal
targetsinautomotiveandindustrialapplications.
Inductivesensingisacontactless,short-range
sensingtechnologythatcanenablehigh-resolution
sensingofconductivetargetsinthepresenceofdust,
dirt,oil,andmoisture,whichcanbeusedby
applicationsinharshenvironments.
TheLDC1001systemconsistsofaninductivesensor,
typicallyaPCBcoil,andaconductivetarget.
TheLDC1001isavailableina16-pinWSON
packageandoffersseveralmodesofoperation.A
serialperipheralinterface(SPI)simplifiesconnection
toanMCU.
DeviceInformation
(1)
PARTNUMBERPACKAGEBODYSIZE(NOM)
LDC1001WSON(16)5.00mm×4.00mm
(1)Forallavailablepackages,seetheorderableaddendumat
theendofthedatasheet.
AxialDistanceSensingApplication
