CSD25310Q2 20V P-Channel NexFET

™

Power MOSFETs

1 Features

•Ultra-low Q

g

and Q

gd

•Low on resistance

•Low thermal resistance

•Pb-free

•RoHS compliant

•Halogen free

•SON 2mm × 2mm plastic package

2 Applications

•Battery management

•Load management

•Battery protection

3 Description

This 19.9mΩ, –20V P-Channel device is designed to

deliver the lowest on resistance and gate charge in

the smallest outline possible with excellent thermal

characteristics in an ultra-low profile. Its low on

resistance coupled with an extremely small footprint

in a SON 2mm × 2mm plastic package make the

device ideal for battery operated space constrained

operations.

0

8

16

24

32

40

48

56

64

72

80

012345678

−V

GS

- Gate-to- Source Voltage (V)

R

DS(on)

- On-State Resistance (mΩ)

T

C

= 25°C, I

D

= −5A

T

C

= 125°C, I

D

= −5A

G001

R

DS(on)

vs V

GS

0

0.5

1

1.5

2

2.5

3

3.5

4

4.5

5

00.511.522.533.544.55

Q

g

- Gate Charge (nC)

−V

GS

- Gate-to-Source Voltage (V)

I

D

= −5A

V

DS

= −10V

G001

Gate Charge

Product Summary

T

A

= 25°CTYPICAL VALUEUNIT

V

DS

Drain-to-Source Voltage–20V

Q

g

Gate Charge Total (–4.5V)3.6nC

Q

gd

Gate Charge Gate to Drain0.5nC

R

DS(on)

Drain-to-Source On Resistance

V

GS

= –1.8V59.0mΩ

V

GS

= –2.5V27.0mΩ

V

GS

= –4.5V19.9mΩ

V

GS(th)

Threshold Voltage-0.85V

.

Ordering Information

DeviceMediaQtyPackageShip

CSD25310Q27-Inch Reel3000SON 2mm x

2mm

Plastic Package

Tape and

Reel

CSD25310Q2T7-Inch Reel250

Absolute Maximum Ratings

T

A

= 25°CVALUEUNIT

V

DS

Drain-to-Source Voltage–20V

V

GS

Gate-to-Source Voltage±8V

I

D

Continuous Drain Current (Package Limit)–20A

Continuous Drain Current(1)–9.6A

I

DM

Pulsed Drain Current(2)48A

P

D

Power Dissipation

1.R

θJA

= 43°C/W on 1 in² Cu (2 oz.) on

.060-inch thick FR4 PCB.

2.9W

T

J

,

T

stg

Operating Junction and Storage

Temperature Range

–55 to 150°C

1S

2

S

S

3

S

4

S

5

G

6

DD

P0112-01

Top View

CSD25310Q2

SLPS459C – JANUARY 2014 – REVISED FEBRUARY 2025

An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,

intellectual property matters and other important disclaimers. PRODUCTION DATA.
