Product

Folder

Sample &

Buy

Technical

Documents

Tools &

Software

Support &

Community

Reference

Design

AnIMPORTANTNOTICEattheendofthisdatasheetaddressesavailability,warranty,changes,useinsafety-criticalapplications,

intellectualpropertymattersandotherimportantdisclaimers.PRODUCTIONDATA.

CC2640

SWRS176B–FEBRUARY2015–REVISEDJULY2016

CC2640SimpleLink™Bluetooth

®

WirelessMCU

1DeviceOverview

1

1.1Features

1

•Microcontroller

–PowerfulARM

®

Cortex

®

-M3

–EEMBCCoreMark

®

Score:142

–Upto48-MHzClockSpeed

–128KBofIn-SystemProgrammableFlash

–8KBofSRAMforCache

–20KBofUltralow-LeakageSRAM

–2-PincJTAGandJTAGDebugging

–SupportsOver-The-AirUpgrade(OTA)

•Ultralow-PowerSensorController

–CanRunAutonomousFromtheRestofthe

System

–16-BitArchitecture

–2KBofUltralow-LeakageSRAMforCodeand

Data

•EfficientCodeSizeArchitecture,PlacingDrivers,

Bluetooth

®

LowEnergyController,andBootloader

inROM

•RoHS-CompliantPackages

–4-mm×4-mmRSMVQFN32(10GPIOs)

–5-mm×5-mmRHBVQFN32(15GPIOs)

–7-mm×7-mmRGZVQFN48(31GPIOs)

•Peripherals

–AllDigitalPeripheralPinsCanBeRoutedto

AnyGPIO

–FourGeneral-PurposeTimerModules

(Eight16-BitorFour32-BitTimers,PWMEach)

–12-BitADC,200-ksamples/s,8-ChannelAnalog

MUX

–ContinuousTimeComparator

–Ultralow-PowerAnalogComparator

–ProgrammableCurrentSource

–UART

–2×SSI(SPI,MICROWIRE,TI)

–I2C

–I2S

–Real-TimeClock(RTC)

–AES-128SecurityModule

–TrueRandomNumberGenerator(TRNG)

–10,15,or31GPIOs,DependingonPackage

Option

–SupportforEightCapacitive-SensingButtons

–IntegratedTemperatureSensor

•ExternalSystem

–On-ChipinternalDC-DCConverter

–VeryFewExternalComponents

–SeamlessIntegrationWiththeSimpleLink™

CC2590andCC2592RangeExtenders

–PinCompatibleWiththeSimpleLinkCC13xxin

4-mm×4-mmand5-mm×5-mmVQFN

Packages

•LowPower

–WideSupplyVoltageRange

•NormalOperation:1.8to3.8V

•ExternalRegulatorMode:1.7to1.95V

–Active-ModeRX:5.9mA

–Active-ModeTXat0dBm:6.1mA

–Active-ModeTXat+5dBm:9.1mA

–Active-ModeMCU:61µA/MHz

–Active-ModeMCU:48.5CoreMark/mA

–Active-ModeSensorController:8.2µA/MHz

–Standby:1µA(RTCRunningandRAM/CPU

Retention)

–Shutdown:100nA(WakeUponExternal

Events)

•RFSection

–2.4-GHzRFTransceiverCompatibleWith

BluetoothLowEnergy(BLE)4.2Specification

–ExcellentReceiverSensitivity(–97dBmfor

BLE),Selectivity,andBlockingPerformance

–Linkbudgetof102dBforBLE

–ProgrammableOutputPowerupto+5dBm

–Single-EndedorDifferentialRFInterface

–SuitableforSystemsTargetingComplianceWith

WorldwideRadioFrequencyRegulations

•ETSIEN300328(Europe)

•EN300440Class2(Europe)

•FCCCFR47Part15(US)

•ARIBSTD-T66(Japan)

•ToolsandDevelopmentEnvironment

–Full-FeatureandLow-CostDevelopmentKits

–MultipleReferenceDesignsforDifferentRF

Configurations

–PacketSnifferPCSoftware

–SensorControllerStudio

–SmartRF™Studio

–SmartRFFlashProgrammer2

–IAREmbeddedWorkbench

®

forARM

–CodeComposerStudio™
