ADC0831-N,ADC0832-N,ADC0834-N,ADC0838-N

www.ti.com

SNAS531B–AUGUST1999–REVISEDMARCH2013

ADC0831-N/ADC0832-N/ADC0834-N/ADC0838-N8-BitSerialI/OA/DConverterswith

MultiplexerOptions

CheckforSamples:ADC0831-N,ADC0832-N,ADC0834-N,ADC0838-N

1

FEATURES

KEYSPECIFICATIONS

2

•TIMICROWIRECompatible—DirectInterfaceto

•Resolution:8Bits

COPSFamilyProcessors

•TotalUnadjustedError:±½LSBand±1LSB

•EasyInterfacetoAllMicroprocessors,or

•SingleSupply:5V

DC

Operates“Stand-Alone”

•LowPower:15mW

•OperatesRatiometricallyorwith5V

DC

Voltage

•ConversionTime:32μs

Reference

•NoZeroorFull-ScaleAdjustRequired

DESCRIPTION

•2-,4-or8-ChannelMultiplexerOptionswith

TheADC0831seriesare8-bitsuccessive

AddressLogic

approximationA/DconverterswithaserialI/Oand

configurableinputmultiplexerswithupto8channels.

•ShuntRegulatorAllowsOperationwithHigh

TheserialI/OisconfiguredtocomplywiththeTI

VoltageSupplies

MICROWIREserialdataexchangestandardforeasy

•0Vto5VInputRangewithSingle5VPower

interfacetotheCOPSfamilyofprocessors,andcan

Supply

interfacewithstandardshiftregistersorμPs.

•RemoteOperationwithSerialDigitalDataLink

The2-,4-or8-channelmultiplexersaresoftware

•TTL/MOSInput/OutputCompatible

configuredforsingle-endedordifferentialinputsas

wellaschannelassignment.

•0.3in.StandardWidth,8-,14-or20-PinPDIP

Package

Thedifferentialanalogvoltageinputallowsincreasing

•20PinPLCCPackage(ADC0838-NOnly)thecommon-moderejectionandoffsettingtheanalog

zeroinputvoltagevalue.Inaddition,thevoltage

•SOICPackage

referenceinputcanbeadjustedtoallowencoding

anysmalleranalogvoltagespantothefull8bitsof

resolution.

TypicalApplication

1

Pleasebeawarethatanimportantnoticeconcerningavailability,standardwarranty,anduseincriticalapplicationsof

TexasInstrumentssemiconductorproductsanddisclaimerstheretoappearsattheendofthisdatasheet.

2Alltrademarksarethepropertyoftheirrespectiveowners.

PRODUCTIONDATAinformationiscurrentasofpublicationdate.

Copyright©1999–2013,TexasInstrumentsIncorporated

ProductsconformtospecificationsperthetermsoftheTexas

Instrumentsstandardwarranty.Productionprocessingdoesnot

necessarilyincludetestingofallparameters.
