POWER

Secondary output

Primary output

Characteristics

2-channel simultaneous charging;

4-level LED charging indicators;

2-channel simultaneous adapting output

Caution

1. Only work in the temperature between 0

-40.

2. Keep the terminals clean and ensure the reliable

connection.

3. Do not cover the cooling vent.

4. Never try to open the product.

5. Do not touch water or use it in wet environment.

6. Do not use metal or other conductors to touch the inside of

the charger.

Compatible Batteries

S-3602F: SWIT S-8972/8970/8770, SONY NP-F970/770

S-3602M: SWIT S-8M91/8M71, SONY NP-QM91/71

S-3602P: SWIT S-8D62/8D54/8D28, Panasonic CGA-D54S

S-3602B: SWIT S-8BG6, Panasonic VW-VBG6

S-3602J: SWIT S-8428, JVC BN-V428U

S-3602V: SWIT S-8823, JVC BN-VF823

S-3602C: SWIT S-8945/8845, Canon BP-945/970G

S-3602

: SWIT S-8

50, JVC SSL-JVC50

Charging

1. Connect with power lead, the charger is automatically

switched on.

2. Mount the compatible batteries onto the charging slot, and

the LED charging indicator will start to flash and indicates

the current capacity of each battery. (25%, 50%, 75% and

100%)

3. When the battery is fully charged, all the 4 LEDs will light

on and stop flashing.

Adapting output

1. There are two 5.5mm pole DC output sockets: Primary

output and Secondary output.

2. Connect the adaptor power lead into DC socket, and the

Adaptor indicator will lights on.

3. The two channels output simultaneously and offers totally

3.5A current.

4. If only use one channel DC output, please connect to

Primary output socket.

Specifications

USER MANUAL

SWIT Electronics Co., Ltd.

Tel:+86-25-85805753

Fax:+86-25-85805296

http://www.swit.cc

E-mail: [email protected]

Power input

100~240VAC, 50/60Hz

Charging output

DC 7V-8.4V, 1.8A×2

Adapting output

DC 8.4V, 3.5A in total

Power consumption

Max 50W

Dimension

136×110×47mm

Mass

360g

S-3602F/P/J/C/M/E/B/V/ Charger/Adaptor I

Battery

Indicator

ADAPTOR 1

ADAPTOR 2
