Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: December 5, 2024

Rear Side

Front Side

Product ID (HB31C5A2CME)

7-Port Industrial USB-C Hub - USB 3.2 10Gbps, ESD Protection

ComponentFunction

1DC Power Input7~24 V • Connect a +DC Power Source

2

DC 2-Wire Terminal Block

Power Input

• Connect a +7~24 V DC Power Source

3

Screw Locking USB-C Host

Port

• Connect to a USB-C or USB-A Port on a Host

Computer

• USB 3.2 Gen 2 (10 Gbps)

Product Diagram

12

4

3

6

7

4Power LED

• Indicates if the USB hub is receiving power

from either a USB Host or a DC Power Source

• Solid Green - Receiving Power

• O - Not Receiving Power

5Mounting Brackets

• Wall mount the USB Hub

• Mount the USB Hub to the side/underside of

a Desk

6

7x Screw Locking USB

Data/Charge Ports

(5x USB-A / 2x USB-C)

• Connect to USB-A and USB-C Peripherals

• USB 3.2 Gen 2 (10 Gbps)

• USB-A Ports Support BC 1.2 for up to 5

V/1.5 A (7.5 W) Charging

• USB-C Ports Support up to 5 V/3 A (15 W)

Charging

77x USB Port Status LEDs

• Indicates if a USB Peripheral is Connected to

the Corresponding Port

• Solid Green - USB Peripheral is Connected

• O - USB Peripheral is Not Connected

Requirements

Host Computer

• USB-C or USB-A Port

Mounting Tools (Optional)

• Mounting Screws x 2

• Phillips or Flat Head Screwdriver

• Writing Utensil

• Level

For the latest drivers, manuals, product information, technical specications, and

declarations of conformance, please visit: www.StarTech.com/HB31C5A2CME

Package Contents

• USB Hub x 1

• 3.3 ft [1 m] USB-C to USB-C Locking Cable x 1

• 3.3 ft [1 m] USB-A to USB-C Locking Cable x 1

• Terminal Block Connector (Attached to the terminal block power adapter)

• Terminal block Power Adapter (NA, JP, UK, EU, ANZ) x 1

• Quick-Start Guide x 1

5
