Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: January 14, 2021
7
6
11
9
*CTK55PCEDRIVE
1
5
3
4
2
*CTK55PCEDRIVE
Product Diagram (CTKxxPCEDRIVE)
Package Contents
Bit Extender, Storage Tube, and Electric Screwdriver
PortFunction
1Case
• Holds the Bits, Demagnetizing Tool, and the Storage
Tube containing the Electric Screwdriver
• CTK20PCEDRIVE features a Soft-shell Case
2AAA Batteries x 2• 3V DC AAA Batteries
20/55-bit Precision Electric Screwdriver with Alkaline Battery
3Demagnetizing Tool
• Magnetize Bits
• Move the Bit around the inside of the square
portion of the Demagnetizing Tool
• Demagnetize Bits
• Move the Bit around theinside of the U-shaped
portion of the Demagnetizing Tool
4
20 Bits
(CTK20PCEDRIVE)
55 Bits
(CTK55PCEDRIVE)
CTK20PCEDRIVE:
H4X28 x 20 Pieces
Philips (PH000, PH00, PH0, PH1)
Slot/Flat (SL1.0, SL1.5, SL2.0)
TORX (T5)
TORX Security (T6, T8)
Hexagonal (H2.5, H3.0)
Pentalobe (P2(0.8), P5(1.2), P6(1.5))
Spanner (U3.0)
TriWing (Y0.6, Y2.5)
Triangle (Δ3.0)
Square/Robertson (S0)
CTK55PCEDRIVE:
H4X28 x 50 Pieces
Philips (PH0000, PH000, PH00, PH0, PH1, PH2)
Hexagonal (H0.7, H0.9, H1.3, H1.5, H2.0, H2.5, H3.0, H3.5,
H4.0)
Slot/Flat (SL1.0, SL1.5, SL2.0, SL2.5, SL3.0, SL3.5)
TORX (T2, T3, T4, T5)
TORX Security (T6, T7, T8, T9, T10, T15, T20)
Triangle (Δ2.0, Δ2.3, Δ2.5, Δ3.0)
TriWing (Y0.6, Y1.0, Y2.0, Y2.5, Y3.0)
Spanner (U2.0, U2.6, U3.0)
Pentalobe (P2(0.8), P5(1.2), P6(1.5))
Square/Robertson (S0, S1, S2)
H4X45 x 5 Micro Pieces
Philips (PH0, PH2)
Hexagonal (H2.0, H2.5)
Slot/Flat (SL2.5)
5
Magnetic Work Pad
(CTK55PCEDRIVE
only)
• Holds magnetized Bits and Screws
6
Bit Extender
(CTK55PCEDRIVE
only)
• Insert into the Electric Screwdriver to extend the Bits
7
Storage Tube
(CTK55PCEDRIVE
only)
• Storage Tube for the Electric Screwdriver
8
10
Product specificaties
| Merk: | StarTech.com |
| Categorie: | Schroefmachine |
| Model: | CTK55PCEDRIVE |
| Kleur van het product: | Zilver |
| Gewicht: | 412 g |
| Breedte: | 16 mm |
| Diepte: | 180 mm |
| Hoogte: | 16 mm |
| Gewicht verpakking: | 800 g |
| Breedte verpakking: | 117 mm |
| Diepte verpakking: | 285 mm |
| Hoogte verpakking: | 40 mm |
| Stroombron: | Batterij/Accu |
| Duurzaamheidscertificaten: | CE, RoHS |
| Stationair toerental (max): | 110 RPM |
| Maximum koppel: | 0.35 Nm |
| Inclusief batterij: | Ja |
| Instelbaar aandraaimoment: | Ja |
| Moment (min): | 0.25 Nm |
| Handgreepvorm: | Rechte handgreep |
| Aantal inbegrepen batterijen: | 2 stuk(s) |
| Aantal bits: | 55 stuk(s) |
| (Buitenste) hoofdverpakking hoogte: | 255 mm |
| (Buitenste) hoofdverpakking breedte: | 300 mm |
| (Buitenste) hoofdverpakking lengte: | 425 mm |
| Hoeveelheid per (buitenste) hoofdverpakking: | 20 stuk(s) |
| Type product: | Elektrische schroevendraaier |
| Batterijtechnologie: | Alkaline |
| Schroevendraaier kopjes meegeleverd: | Hex (imperial), Pentalobe, Phillips, Robertson, Slot, Spanner, Torx, Tri-Wing, Triangle |
