Instructions for Models:
S-1566
S-1566-BN
S-1566-PN
Need Help?
For additional assistance or service call:
SPEAKMAN Company
400 Anchor Mill Road
New Castle, DE 19720
PHONE: 800-537-2107
EMAIL: customerservice@speakmancompany.com
WEB: www.speakmancompany.com
92-S-1566-R1
What You Need To Know:
Tools:
Required:
*Allen Wrench (Included)
Helpful:
Important Notes:
Be sure to read instructions thoroughly before
beginning installation. Do not overtighten any
connections or damage may occur.
Safety Tips:
Cover your drain to prevent loss of parts.
Be sure to wear eye protection while cutting pipe.
Maintenance:
Your new Tub Spout is designed for years of
trouble-free performance. Keep it looking new by
cleaning it periodically with a soft cloth. Avoid
abrasive cleaners, steel wool and harsh chemicals
as these will dull the finish and void your warranty.
*Hacksaw*Tubing Cutter
*nEye Protectio
①
The minimum distance between the center off
the tub spout and the rim of the tub should be
no less than 4".
The stub out for the 1/2" pipe should extend
a minimum of 1.5" from the wall, but not to
exceed 3" from wall. Remove all burs and
sharp edges from the stub out 1/2" pipe.
Slide spout (1) over exposed stub out pipe until
flush to wall. Center the spout (1) on the wall
and tighten set screw (2) from underneath with
allen wrench (Hex: 3.97mm) provided.
②
③
4'' Minimum
1.5'' - 3.0''
MIN MAX
1
2
5.43''
[137.80mm]
2.59''
[65.73mm]
2.27''
[57.73mm]
1/4"-20UNC-2A
THREAD
①
②
