INSTRUCTIONS FOR MODELS
92-S-1574-02
For additional assistance or service please contact:
SPEAKMAN
®
Company
400 Anchor Mill Road
New Castle, DE 19720
800-537-2107
customerser[email protected]
www.speakman.com
S-1574
CDS1574
TOOLS AND SUPPLIES
IMPORTANT
SAFETY TIPS
Cover your drain to prevent loss of parts. Be sure to
wear eye protection while cutting pipe.
MAINTENANCE
Your new Speakman product is designed for years
of trouble-free performance. Keep it looking new by
cleaning it periodically with a soft cloth. Avoid
abrasive cleaners, steel wool, and harsh chemicals
as these will dull the finish and void your warranty.
WARRANTY
Warranty information can be found at:
www.speakman.com
• Be sure to read instructions thoroughly before
beginning installation.
• Do not over-tighten any connections or damage
may occur.
Pipe
Wrench
Plumber’s
Putty
1
Verify rough in distance of supply pipe. The
minimum distance between the center of the tub
spout and the rim of the tub should be no less
than 4".
4'' Minimum
2
The stub out for the 1/2" pipe should be flush to
recessed by ¼” from the finished wall. Remove
all burs and sharp edges from the stub out 1/2"
pipe. Plumber's Putty should be applied to the
threads for sealing.
1/2"-14NPT
WATER INLET
(NOT SUPPLIED)
FLUSH TO 1/4"
RECESSED
INSIDE THE WALL
27mm
1-1/16"
MIN.
3
Engage the threads and rotate Spout (1)
clockwise over the stub out pipe until tight and
flush to wall. Center the Spout on the wall. Make
sure to firmly tighten. Outlet port should be
pointing downward when complete.
4
Turn on water supplies and check for leaks.
Optional: Apply silicone where the flange meets
the wall.
