Box contents

1 Surface-mount bracket

1 Safety cable

Install Instructions For:

1.435.647.9555

| 800.647.TUBE |

www.soundtube.com

Wall-plate hole pattern

RS600i, RS800i, RS1001i-II, HP690i, HP890i

40.9 mm

(1.61 in)

ø7.1 mm

(.28 in)

40.9 mm

(1.61 in)

41.4 mm

(1.63 in)

82.6 mm

(3.25 in)

102.9 mm

(4.05 in)

RSi & HP Series

38.1 mm

(1.50 in)

86.4 mm

(3.40 in)

119.4 mm

(4.70 in)

38.1 mm

(1.50 in)

124.5 mm

(4.90 in)

Wall-plate hole pattern

HP129i, HP1290i

Transformer Taps Settings

Treaded insert

Insert cover

Terminal weather boot

Mounting bolt and washer

Signal wire

Safety cable nut, washer & bolt

Safety cable

Surface-mount bracket

Nylock nut

Wall-plate

Wall-plate

stud

70.7 Volt Transformer Taps (dB)100 Volt Transformer Taps (dB)25 Volt Transformer Taps (dB)

Voice Coil

© 2008 SoundTube Entertainment, Inc. All rights reserved. PN INS-RS Rev 05.12.08

RS600i

RS800i

RS1001i-II

Warning

150W=112.5, 75W=109.5, 38W=106.5 19W=103.5

66W=110.5, 35W=108, 19W=105.5, 10W=102.5, 5W=99.5

150W=112.5, 75W=109.5, 38W=106.5

66W=110.5, 35W=108, 19W=105.5, 10W=102.59W=102, 4.5W=99, 2.3W=96, 1.1W=93

19W=103.5, 9.5W=100.5, 4.8W=97.5, 2.4W=94.5

8 Ohm=112 dB

4 Ohm=112.5 dB

33W=105.5, 17W=103, 9W=100, 6W=98.5, 3W=95.533W=105.5, 17W=103, 9W=100, 6W=98.5

5W=97.5, 2.5W=94.5, 1.3W=91.5, .63W=88.5

8 Ohm=111 dB

HP890i

HP129i

HP1290i

8 Ohm=119 dB

8 Ohm=120 dB

8 Ohm=111 dB

150W=120, 75W=117, 38W=114 19W=111 150W=120, 75W=117, 38W=114

19W=111, 9.5W=108, 4.8W=105, 2.4W=102

150W=119, 75W=116, 38W=113 19W=110 150W=119, 75W=116, 38W=113

19W=110, 9.5W=107, 4.8W=104, 2.4W=101

120W=115, 64W=112, 32W=109 16W=106120W=115, 64W=112, 32W=109 16W=106

16W=106, 8W=103, 3.8W=100, 1.9W=97

66W=111, 35W=108.5, 19W=106 10W=103, 5W=100 66W=111, 35W=108.5, 19W=106 10W=103

9W=100, 2.5W=97, 1.25W=94, .75W=92

HP690i

8 Ohm=117 dB

RS600i, RS800i, RS1001i-II, HP690i, HP890i, HP129i, HP1290i speakers
