Display Cabinet
Display Controller
Operating Instructions
Before operating the unit, please read this manual and the supplied Before Using This Unit document thoroughly and retain
it for future reference.
ZRD-CH12D/ZRD-CH15D/ZRD-BH12D/ZRD-BH15D
ZRD-C12A/ZRD-C15A/ZRD-B12A/ZRD-B15A
ZRCT-300
ZRK-CH12D/ZRK-CH15D/ZRK-BH12D/ZRK-BH15D
ZRA-CH12DSM/ZRA-CH15DSM/ZRA-BH12DSM/ZRA-BH15DSM
ZRA-1DSC
ZRA-1DSK
5-029-334-16 (1)
© 2021 Sony Corporation
2
Table of Contents
Please Read This First ..................................3
Manual Structure .....................................3
Condensation ..........................................3
Security ....................................................3
Burn-in .....................................................3
Defective pixels ...................................... 4
General Precautions ............................... 4
Precautions on viewing and displaying
3D images ............................................... 4
Precautions on the environment when
displaying 3D images ............................. 4
Precautions regarding the effect on
medical devices ...................................... 4
Precautions on visually induced motion
sickness (VIMS) and postural
instability .................................................5
Other precaution .....................................5
Overview ..................................................... 6
System Configuration Diagram .............. 6
Parts Identification .......................................7
Display Cabinet .......................................7
ZRCT-300 Display Controller .................. 9
Turning the Power On/Off ..........................11
Turning the Power On ............................11
Turning the Power Off ........................... 12
Selecting the Video Input .......................... 13
Changing the Display Starting Positions
of Pictures .............................................. 14
Configuring the Input Level and Signal
Format for HDMI Inputs ......................... 15
Displaying a Black Picture on the
Screen .................................................... 15
Adjusting the Picture Quality .....................16
Displaying 3D Video ................................... 19
Displaying the test pattern for each Display
Cabinet ...................................................... 20
Displaying the selected test pattern on
a Display Cabinet .................................. 21
Synchronizing with External Sync
Signals ........................................................22
Inputting External Sync Signals ............22
Enabling External Synchronization .......22
Synchronizing with the camera being
used for shooting ..................................22
Using Network Features .............................24
Displaying the Control Window of the
Display Controller with a Web
Browser ..................................................25
Setting the Control Protocol of the
Display Controller ..................................26
Troubleshooting .........................................27
Error Codes ................................................ 29
Display Cabinets ................................... 29
Display Controllers ................................30
Cleaning and Storage .................................31
Display Cabinets ....................................31
Display Controllers .................................31
Signal Formats ............................................31
2D Inputs ................................................31
3D Inputs ............................................... 32
Supported Signal Formats for a Single
Controller .............................................. 33
NOTICES AND LICENCES FOR SOFTWARE
USED IN THIS PRODUCT ............................. 35
Trademarks
• Products or system names appearing in this
document are trademarks or registered
trademarks of their respective owners.
Further, the ® or ™ symbols are not used in the
text.
• The terms HDMI and HDMI High-Definition
Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI
Licensing Administrator, Inc. in the United
States and other countries.
• DisplayPort is a trademark or registered
trademark of Video Electronics Standards
Association in the United States and other
countries.
• Reproduction or duplication, in whole or
part, of the operation manual supplied with
the system without the authorization of the
right holder is prohibited under copyright
law.
• Note that the specifications of the system
are subject to change for improvement
without prior notice.
