Table of Contents

IMPORTANT NOTICE . . . . . . . . . . . . . . . . 2

Safety Information . . . . . . . . . . . . . . . . . 2

Connection Diagram . . . . . . . . . . . . . .4

Remote Control and LCD Monitor. . . .6

Settings. . . . . . . . . . . . . . . . . . . . . . . . .7

Pro mode. . . . . . . . . . . . . . . . . . . . . . . . . 7

Recommended settings. . . . . . . . . . . . . 8

Control functions . . . . . . . . . . . . . . . . .9

RS-232C . . . . . . . . . . . . . . . . . . . . . . . . . . 9

IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Appendix . . . . . . . . . . . . . . . . . . . . . . 12

Extended software . . . . . . . . . . . . . . . . 12

Installing the LCD Monitor to

the Wall. . . . . . . . . . . . . . . . . . . . . . . . 13

Troubleshooting. . . . . . . . . . . . . . . . . 15

Specifications . . . . . . . . . . . . . . . . . . . 15

Note

• Before operating the LCD Monitor, please read the “Safety

Information”.

• Read the supplied safety documentation for additional safety

information.

• Images and illustrations used in the Setup Guide and this

manual are for reference only and may differ from the actual

product.

Location of the identification label

Labels for the LCD Monitor Model No., Production Date (year/

month) and Power Supply rating are located on the rear of the

LCD Monitor or package.

IMPORTANT NOTICE

Notice for Radio Equipment

Hereby, Sony Corporation declares that the radio equipment

types FW-85BZ40H, FW-75BZ40H, FW-65BZ40H, FW-55BZ40H are

in compliance with Directive 2014/53/EU. The full text of the EU

declaration of conformity is available at the following internet

address: http://www.compliance.sony.eu/

Notice for customers: the following information is only applicable

to equipment sold in countries applying EU directives.

For this radio equipment, the following restrictions on putting into

service or of requirements for authorization of use apply in AT, BE,

HR, CY, CZ, DK, EE, FI, FR, DE, EL, HU, IE, IT, LV, LT, LU, MT, NL, PL,

PT, SK, SI, ES, SE, UK, IS, LI, NO, CH, BG, RO, TR, AL, BA, MK, MD,

RS, ME, Kosovo :

5150 - 5350 MHz band is restricted to indoor operations only.

Safety Information

Installation/Set-up

Install and use the LCD Monitor in accordance with the

instructions below in order to avoid any risk of fire, electric shock

or damage and/or injuries.

Installation

• The LCD Monitor should be installed near an easily accessible

mains socket.

• Place the LCD Monitor on a stable, level surface to prevent it

from falling over and causing personal injury or property

damage.

• Install the LCD Monitor where it cannot be pulled, pushed, or

knocked over.

• Install the LCD Monitor so that the LCD Monitor’s Table-Top

Stand does not protrude out from the LCD Monitor stand (not

supplied). If the Table-Top Stand protrudes out from the LCD

Monitor stand, it may cause LCD Monitor set to topple over, fall

down, and cause personal injury or damage to the LCD Monitor.

About Manuals

This LCD Monitor comes with the following

manuals. Please retain the manuals for future

reference.

Setup Guide

•LCD Monitor

installation and setup.

Reference Guide (this

manual) / Safety

Documentation

• Safety information, remote

control, troubleshooting, wall-mount

installation, specification, etc.

Help

Find more troubleshooting and

other useful information directly

from your LCD Monitor. Press HELP

on the remote control to display a

list of topics.

IMPORTANT - Read the End User Software Licence

Agreement before using your Sony product. Using your

product indicates your acceptance of the End User Software

Licence Agreement. The software licence agreement between

you and Sony is available online at Sony website (http://

www.sony.net/tv-software-licenses/) or on your product

screen. Go to [Settings] t [Device Preferences] t [About] t

[Legal information] t [Notices and licences].
