Pagina 1/316

D:\_SONY TV\SY21_B2B_EU_RG_131\5027087131\01GB\5027087131_01GB.fm master page: Cover

5-027-087-13(1)

Reference Guide

Guide de référence

Guía de referencia

Referentiegids

Referenzanleitung

Guia de referência

Guida di riferimento

Referensmaterial

Referencevejledning

Viiteopas

Referanseveiledning

Przewodnik

Οδηγός αναφοράς

Başvuru Kılavuzu

Справочник

Довідковий посібник

LCD Monitor

FW-100BZ40J / 75BZ30J / 65BZ30J / 55BZ30J1 / 55BZ30J / 50BZ35J / 50BZ30J / 43BZ35J / 43BZ30J / 32BZ30J

5-027-087-13(1)

FW-100BZ40J / 75BZ30J / 65BZ30J / 55BZ30J1 / 55BZ30J

FW-50BZ35J / 50BZ30J / 43BZ35J / 43BZ30J / 32BZ30J

D:\_SONY TV\SY21_B2B_EU_RG_131\5027087131\01GB\5027087131_01GB.fm master page: Left

FW-100BZ40J / 75BZ30J / 65BZ30J / 55BZ30J1 / 55BZ30J / 50BZ35J / 50BZ30J / 43BZ35J / 43BZ30J / 32BZ30J

5-027-087-13(1)

Table of Contents

IMPORTANT NOTICE . . . . . . . . . . . . . . . . 2

Safety Information . . . . . . . . . . . . . . . . . 2

Connection Diagram . . . . . . . . . . . . . .4

Remote Control and LCD Monitor. . . .7

Settings. . . . . . . . . . . . . . . . . . . . . . . . .8

Pro mode. . . . . . . . . . . . . . . . . . . . . . . . . 8

Recommended settings. . . . . . . . . . . . . 9

Control functions . . . . . . . . . . . . . . . .10

RS-232C . . . . . . . . . . . . . . . . . . . . . . . . . 10

IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Appendix . . . . . . . . . . . . . . . . . . . . . . 13

Extended software . . . . . . . . . . . . . . . . 13

Installing the LCD Monitor to

the Wall. . . . . . . . . . . . . . . . . . . . . . . .14

Troubleshooting. . . . . . . . . . . . . . . . . 15

Specifications . . . . . . . . . . . . . . . . . . . 15

Setting menus are subject to change without notice.

Note

• Before operating the LCD Monitor, please read the “Safety

Information”.

• Read the supplied safety documentation for additional safety

information.

• Images and illustrations used in the Setup Guide and this

manual are for reference only and may differ from the actual

product.

Location of the identification label

Labels for the LCD Monitor Model No., Production Date (year/

month) and Power Supply rating are located on the rear of the

LCD Monitor or package.

For models with supplied mains adaptor:

Labels for mains adaptor Model No. and Serial No. are located on

the bottom of mains adaptor.

Notice for Radio Equipment

Hereby, Sony Corporation declares that the radio equipment

types FW-100BZ40J, FW-75BZ30J, FW-65BZ30J, FW-55BZ30J1,

FW-55BZ30J, FW-50BZ35J, FW-50BZ30J, FW-43BZ35J,

FW-43BZ30J, FW-32BZ30J are in compliance with Directive 2014/

53/EU. The full text of the EU declaration of conformity is available

at the following internet address: https://compliance.sony.eu

Hereby, Sony Corporation declares that the radio equipment

types FW-100BZ40J, FW-75BZ30J, FW-65BZ30J, FW-55BZ30J1,

FW-55BZ30J, FW-50BZ35J, FW-50BZ30J, FW-43BZ35J,

FW-43BZ30J, FW-32BZ30J are in compliance with the UK relevant

statutory requirements. The full text of the declaration of

conformity is available at the following internet address:

https://compliance.sony.co.uk

For this radio equipment, the following restrictions on putting into

service or of requirements for authorization of use apply in AT, BE,

HR, CY, CZ, DK, EE, FI, FR, DE, EL, HU, IE, IT, LV, LT, LU, MT, NL, PL,

PT, SK, SI, ES, SE, UK, UK (NI), IS, LI, NO, CH, BG, RO, TR, AL, BA, MK,

MD, RS, ME, Kosovo :

5150 - 5350 MHz band is restricted to indoor operations only.

Installation/Set-up

Install and use the LCD Monitor in accordance with the

instructions below in order to avoid any risk of fire, electric shock

or damage and/or injuries.

Installation

• The LCD Monitor should be installed near an easily accessible

mains socket.

• Place the LCD Monitor on a stable, level surface to prevent it

from falling over and causing personal injury or property

damage.

• Install the LCD Monitor where it cannot be pulled, pushed, or

knocked over.

About Manuals

This LCD Monitor comes with the following

manuals. Please retain the manuals for future

reference.

Setup Guide

•LCD Monitor

installation and setup.

Reference Guide (this

manual) / Safety

Documentation

• Safety information, remote

control, troubleshooting, wall-mount

installation, specification, etc.

Help

Find more troubleshooting and

other useful information directly

from your LCD Monitor. Press HELP

on the remote control to display a

list of topics.

IMPORTANT - Read the End User Software Licence

Agreement before using your Sony product. Using your

product indicates your acceptance of the End User Software

Licence Agreement. The software licence agreement between

you and Sony is available online at Sony website (https://

www.sony.net/tv-software-licenses/) or on your product

screen. Go to [Settings] t [System] t [About] t [Legal

information] t [Notices and licences].

IMPORTANT NOTICE

Safety Information

Product specificaties

Merk:	Sony
Categorie:	Monitor
Model:	FW-50BZ35J
Kleur van het product:	Zwart
Gewicht verpakking:	19000 g
Breedte verpakking:	1228 mm
Diepte verpakking:	143 mm
Hoogte verpakking:	786 mm
Beeldschermdiagonaal:	50 "
Resolutie:	3840 x 2160 Pixels
Touchscreen:	Nee
USB-poort:	Ja
Ondersteuning voor plaatsing:	Binnen
Typische contrastverhouding:	5000:1
Helderheid:	570 cd/m²
Stroomverbruik (in standby):	0.5 W
High Dynamic Range (HDR)-technologie:	High Dynamic Range 10 (HDR10)
HDR-ondersteuning:	Ja
HD type:	4K Ultra HD
Display technologie:	VA
Responstijd:	6 ms
VESA-montage:	Ja
Paneelmontage-interface:	200 x 200 mm
Model:	Horizontaal/Verticaal
Antireflectiescherm:	Ja
Bedoeld voor:	Universeel
Bedrijfsuren (uren/dagen):	24/7
Computersysteem:	Ja
Contrast ratio (dynamisch):	500000:1
Energieverbruik (HDR) per 1000 uur:	122 kWu
Energie-efficiëntieklasse (SDR):	G
Energieverbruik (SDR) per 1000 uur:	85 kWu
Energie-efficiëntieklasse (HDR):	G
Breedte apparaat (met standaard):	1118 mm
Diepte apparaat (met standaard):	285 mm
Hoogte apparaat (met standaard):	714 mm
Gewicht (met standaard):	13300 g
Dolby Vision:	Ja
Type processor:	Ja
Hybride Log Gamma (HLG):	Ja
LED backlight-type:	Direct-LED
Schermbreedte:	1118 mm
Display diepte:	69 mm
Display hoogte:	649 mm
Display gewicht:	12700 g
Productontwerp:	Digitale signage flatscreen
Wifi:	Ja
Stroomverbruik (typisch):	148 W
Energie-efficiëntieschaal:	A tot G
Code geharmoniseerd systeem (HS):	85285210
High Dynamic Range 10 (HDR10):	Ja
Waasniveau:	2 - 5 procent
