Compactandeasytocarry

Speed meterwithtopspeedmemory

Topaltitude

Built-in 4M flash (recording time: 6 hours)

UTCtimestamploggedforeachtrackpoint

Built-in rechargeable, LiPo bettery 200mAh

(Operating time: 150 minutes)

INSTRUCTIONMANUAL

StopwonderinghowfastyourRCcarcanrunandhowhighyourRCAirplaneorhelicoptercan

fly. NowallthesedatacomeatyourfingerwiththeGPSSPEEDMETERbySkyRC.

ThepopularityofGPSdevicesinspiredSkyRCtodesignthisgadgetatabout41g. TheSpeed

MeteristheresultofSkyRC’songoingdevelopmentefforts, boastinganultracompactGPS

module with hidden antenna design, the high-sensitivity GPS receiver chip can do quick

positioning, arobustcontrollerICtokeeprecordingspeed and altitudeinrealtime.

ThisgadgetisidealforRCracing/flyingandcasualbiking, drivingandlongjourney. Usercould

easilyviewthescreenwhileworkingoutdatasuchas speed, altitudetotalmileage/kilometer,

longitude/latitude.

Thegadgetrecordsthetopspeedandtopaltitudeforinstantrecallaftertherunning. Itwillhelp

RCfansmuchtofine-tunetheirRCgadgetstoachievebetterperformance.

FEATURES

- 1 -- 2 -

GSM-010 GPS SPEED METER

LCDDisplay

Hidden Antenna

MODEButton

ENTERButton

Strap

Hole

USBData

& Charging

Port

Power

Button

ServoPort

PClinkfordatalogging & googlemap

CHARGING BATTERY

Battery

Cover Lid

Charging

Connect the USB cable to your computer and GPS speed meter. The battery icon will blinking

during the charging process.

Fully Charged

PressthePOWERBUTTONtoturniton.

Press and holdthePOWERBUTTON for 6 seconds, “OFF” will be displayed on the LCD

screen. Relese the POWER BUTTON and the device will be power off.

POWERON

POWEROFF

After turn on the power, the meter will startingtheprocessofsatelliteacquisitionandtracking

automatically. Beforeapositionfixiscalculated, theiconofSatelliteReceiverwillkeepblinking.

The metertakesabout30secondstoachieveapositionfixinnormal.

It may take longer than normal to establish an initial position for the first time or if the meter has

not been used for an extended period of time. If the meter is powered on in outdoors with a

clear view of the sky this should not take more than 3-5 minutes.

If your meter is indoors, it may not acquire satellites.(OUTDOORS USED ONLY)

TheiconofSatelliteReceiverwillkeepblinkinguntilapositionfixiscalculated. Itisunderstood

thatsatelliteacquisitiontimedependsonweatherconditionsanduserslocation,

Afterapositionfixhasbeencalculated, theiconofsatellitereceiverandtheUTCtimewillbe

shownonthescreenasbelow.

Blinking

GPS INITIALIZATION

GPS Coordinator

Support both Metric and Imperial system of

measurement

(For external power

source DC 6V)

(ACQUIRE SATELLITES)

Firmware upgradable
