INTRODUCTION

Thank you for purchasing the eFUEL 380W, 16A AC/DC Switching Power Supply.We are confident that you will be very

pleased with its performance because our AC/DC Switching Power Supply is designed and manufactured by skilled

professionals using the highest standard in workmanship.You can be assured of many years of trouble free service.

Your eFUEL AC/DC switching Power Supply is designed to use household AC power source to power equipments that

required DC power. The eFUEL converts standard household power 100-240V AC to 24V DC power and can supply up

to 16 amperes of continuous power.

INSTRUCTION MANUAL



380W,16A AC/DC SWITCHING

POWER SUPPLY

SK-200023

1

2

AC Power

Input Socket

Power

Switch

Cooling

Fan

Cooling

Fan

DC Output

LED

Indicator

Active PFC: smaller AC input current less interference, and Conform to CE Regulations

DC poweroutputs, upto16amperes

Output voltage 24V

AC 100-240V worldwide operation: need not any alternative switcher, worldwide safe operation.

Smart cooling fans turned on upon the temperature automatically

Over current, over voltage, over load and over temperature protection

Short-circuit protection on output, safer and more reliable.

FEATURES

Warning:

This appliance is not intended for use by persons (including children)

with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision

or instruction concerning use of the appliance by a person responsible

for their safety.

Children should be supervised to ensure that they do not play with the

appliance. WARNING: If the surface is cracked, switch off the

appliance to avoid the possibility of electric shock.

Forindooruseonly.

CAUTION:

Your power supply might cause TV or radio interference even when it is operating properly. To determine whether your

power supply is causing the interference, turn off your power supply. If the interference goes away, your power supply is

causing it.

Try to eliminate the interference by:

Moving your power supply away from the receiver.

Connecting your power supply to an outlet that is on a different

electrical circuit from the receiver.

Contacting a qualified service technician for help.

必须连接地线

Must Connect an Earth

Terminal to the Ground

WARNING

OPERATION

To use the power supply after you connect the device to it, turn it on with the power switch.

Please check all connections and confirm the wall AC outlet has power before you switch on the power supply.

In case of an error or overload the LED will turn red.

Efuel 380 is capable of handling up to 380 Watts output. Verify that your equipment plugged into the outlets does not

exceed power rating. Your power supply's overload protection circuit automatically shuts down the power supply when it

is overload and resets by turning POWER to OFF. Reduce the load (by using a device that does not require more than

380 watts), then set POWER to ON.

If you have verified that your connected equipment does not exceed the ratings of the unit and the Overload Led is RED

CONTINUOUSLY, this may indicate an internal fault. If this is the case, please contact us for Technical Support.

OVERLOAD/ERROR INDICATION
