INTRODUCTION

-1--2-

INSTRUCTIONMANUAL

SK-600147

BD350 BATTERY DISCHARGER & ANALYZER

Thanks for choosing SkyRC BD350 discharger.

BD350 discharger supports most RC batteries and works with SkyRC T1000* charger with a discharge

current of up to 40A and discharge power of 350W.

There should be more models to work with, and we will update the website!

OPERATION INSTRUCTION

Discharge

1. Upon connecting the power supply, T1000 automatically powers on and enters the main menu;

2. Connect BD350 discharger to T1000;

Notice:

As of the time of releasing, the BD350 discharger only works with T1000.

Analyze via Charge Master PC Software

BD350 is more than a simple battery discharger. It is a powerful test instrument that

measures, graphs, and compares the parameters of various batteries. It allows for the

precise measuring of battery capacity and performance.

No more guesswork anymore when choosing the best battery for RC racing!

3. Discharge the battery by connecting to T1000 on Port A;

4. Select Discharge: set the cut-off voltage, the discharge current, and the number of cells;

5. Start the program.

SPECIFICATION

Working Voltage:

Discharge Power:

Discharge Current:

Over Temp. Protection:

Working Temp.:

Working Humidity:

Size:

Net Weight:

DC 5V

350W

0.1-40A

o

>95C

oo

0C~40C

0%~75%

157*105*93mm

1224g

EXPLANATION OF STATUS LEDS

Stays Green

Stays Red

Flashes Red

Standby

Discharging

Error

LEDStatus

LiPo Battery

*
