www.silverstonetek.com
User manual
5U rackmount server chassis
with enhanced liquid cooling compatibility
RM53-502
A
E
FG
H
D
I
B
C
A:Foot padB:Foot pad screwC:Foot pad rubber
E:Handlebar
bracket screws
H:L-shaped
brackets
F :Handlebar
brackets
G:Handlebars
D:Cable tie
I:Cable
management
buckle
Accessories Content
User manual
PSU mounting screws2.5” SSD screws (M3-5)
Motherboard standoff Motherboard,
5.25" Device Screw
Ǝ66'WUD\screws
3.5” HDD screws (#6-32)
C.80mm fan cage
D.Fan cage screw
$6HFRQGDU\368
extension adapter
B.Extension adapter screw
᧤$᧥᧤&᧥
᧤%᧥
᧤'᧥
1. Remove the four screws securing the upper 5.25" bracket, then
slide it backward to remove it
Hard Drive and Card Holder Instructions
2.Remove the screws from the top and rear to detach the left bracket3.Remove the screws from the top to detach the right bracket
