Accessories Content

Motherboard

standoff

Motherboard,

CRPS standoff

screws

Secure 2.5” SSD,

CRPS standoff

screws

Secure 3.5” HDD,

power supply

screws

Graphics card

rubber

Riser cable

CRPS power

supply bracket

CRPS extension

bracket

Handle bar

bracket screws

Support CRPS,

Riser card standoff

L-shaped bracketHandle bar

1. Remove the graphics card bracket2-1 Remove the drive cage

3.5" or 2.5" Hard Drive Installation

2-2 Install 2x 3.5" or 2x 2.5" hard drive2-3 Install the drive cage

2-4

Space Limitation

80MM239MM

55MM

264MM

30MM

289MM

When the drive position is

set toward the rear:

•PSU clearance: 239 mm

•Front fan/radiator

clearance: 80 mm

When the drive position is

set toward the middle:

•PSU clearance: 264 mm

•Front fan/radiator

clearance: 55 mm

When the drive position is

set toward the front:

•PSU clearance: 289 mm

•Front fan/radiator

clearance: 30 mm

www.silverstonetek.com

User manual

RM32

3U rackmount server chassis supporting

4-slot high-end retail graphics cards and 360mm radiators.
