Digital Color Dome Camera

SCC-520N/520P

User's guide

CCTV COLOR DOME CAMERA SCC-520N/520P is the monitoring

camera incorporated with the recent CCD that provides the best

monitoring function in connection with the CCTV system equipment.

■Number of CCD pixels

•SCC-520N : 270,000 pixels

•SCC-520P: 320,000 pixels

■Power supply

•SCC-520N :

DC 12V

•SCC-520P:

■Automatic function and special function

•ATW

•ELC(Electronic shutter iris)

■Fixed focus lens

•Fixed focus lens installed on the camera.

Please take cautions that any dust or foreign matter gathers

on the front glass surface of the lens.

■Main body

•A body that supports the camera.

■PCB board

•This part is quite important since it performs the camera

function.

Please handle with care.

■Power cable

•The terminal that is connected to the power (adaptor) cable.

Connect to DC 12V.

■Video signal output cable

•The cable that sends the video signal.

■Dome cover

•The transparent plastic cover that protects the camera.

Be careful not to make a scratch on it.

Video cable

Dome cover

Fixed focus lens

PCB board

Main body

Power cable

Component Name

Function of Each Component

Overview
