Personal injury and/or equipment
damage may result if proper safety
precautions are not observed.
• Ensure that the reel has been properly
installed before connecting supply line
(see installation instructions).
• Bleed fluid/gas pressure from system
before servicing reel.
• Before connecting reel to supply line
ensure that supply line pressure does
not exceed maximum rated working
pressure of reel.
• Do not play pranks on other personnel.
Even low pressure is very dangerous
and can cause irrepairable damage or
death.
• Do not wear loose fitting clothing while
operating reel.
• Be aware of other personnel in work
area.
• Be aware of other machinery in work
area.
• If a leak occurs in the hose or reel,
remove supply line pressure
immediately.
• If the reel is power driven check for
loose, frayed, and/or broken wires before
operating.
• Treat and respect a hose reel as any
other piece of machinery, observing all
common safety practices.
Operating Instructions
Series 30000 Hand Crank Reels
Reelcraft Industries, Inc. • 2842 E Business Hwy 30, Columbia City, IN 46725
Ph: 800-444-3134 / 260-248-8188 • Fax: 800-444-4587 / 260-248-2605
Customer Service: 855-634-9109 • [email protected] • www.reelcraft.com
Form# 837-696A Rev: 10/2016
CA30106 LCA32106 MCA32128 LCA33118 M
CA30112 LCA32112 LCA33106 LCA33122 L
CA30118 LCA32112 MCA33106 MCA33128 L
CA30122 LCA32118 LCA33112 L
CA30128 LCA32118 MCA33112 M
CA32106 LCA32122 LCA33118 L
Dimensional Data
Part #ABD
CA30106 L19 3/4”6”9 3/4”
CA30112 L25 3/4”12”15 3/4”
CA30118 L31 3/4”18”21 3/4”
CA30122 L35 3/4”22”25 3/4”
CA30128 L40 3/4”27”30 3/4”
CA32106 L19 3/4”6”9 3/4”
CA32106 M19 3/4”6”9 3/4”
CA32112 L25 3/4”12”15 3/4”
CA32112 M25 3/4”12”15 3/4”
CA32118 L31 3/4”18”21 3/4”
CA32118 M31 3/4”18”21 3/4”
Part #ABD
CA32122 L35 3/4”22”25 3/4”
CA32128 L40 3/4”27”30 3/4”
CA33106 L19 3/4”6”9 3/4”
CA33106 M19 3/4”6”9 3/4”
CA33112 L25 3/4”12”15 3/4”
CA33112 M25 3/4”12”15 3/4”
CA33118 L31 3/4”18”21 3/4”
CA33118 M31 3/4”18”21 3/4”
CA33122 L35 3/4”22”25 3/4”
CA33128 L40 3/4”27”30 3/4”
Safety Precautions
A
A
B
D
