AssemblyInstructionSheet#IS-SDL5005BN
ForStyleSDL5005BN
Pleasegotoforproductcleaningtips.Gototheselection.
(5)A19MediumBaseBulbs100WMaximumor
(5)MediumBaseT10VintageBulbsarerecommendedbutnotsupplied.
30-45minutes
Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagramsbelowtobesureallpartsare
present.Ifanypartsaremissingordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomerserviceforreplacement
parts.
www.quoizel.comCare+Maintenance
LightSource:
EstimatedAssemblyTime:
Preparation:
ToolsRequired:Flatheadscrewdriver,Phillipsscrewdriver,pliers,wirecutters,wirestrippers,electricaltape,safetyglasses.
WarningsandCautions
Turnoffelectricityatcircuitbreakerormainfuseboxbeforeinstallation.Consultalicensedelectricianifindoubt.
Theseinstructionsareprovidedforyoursafety.Itisveryimportantyoureadthemcompletelybeforeinstallingthefixture.Westrongly
recommendthatalicensed,professionalelectricianperformtheinstallation.
Disconnectfixturefrompowersourcebeforereplacingbulbs.Makesurebulbsaregivensufficienttimetocoolbeforeremoval.
PackageContents
A
CrossbarAssembly
x1
ThankyouforpurchasingaQuoizelproduct.
Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-800-645-3184
orvisituson-lineatwww.quoizel.com
FixtureBody
x1
2017QuoizelInc.
ReleasedDate:2017-08-10
D
CeilingCanopy
x1
B
6”Rod
x2
C
12”Rod
x2
Glass
Shade
x5
G
E
F
LockScrew
x15
STEP1-InstallCeilingCanopy,Rodsand
FixtureBodytogether
A.DeterminetheRods(B/C)tobeassembled
totheFixtureBody(E)andfixturebody
accordingtoyourhangingheight.
B.Passthesupplywiresandgroundwire
throughthechosenrods(B/C)andthe
CeilingCanopy(D).ThreadtheFixture
Body(E),thechosenRods(B/C)andthe
CeilingCanopy(D)together.Handtighten
untilsnug.
B
B
D
SupplyWires
andGroundWire
C
E
C
Figure1
STEP2-InstallingtheCrossbarAssembly
A.PassthesupplywiresfromoutletboxthroughtheCrossbar
Assembly(A).AttachtheCrossbarAssembly(A)totheOutletBox
withtheheadoftheGreenGroundScrewfacingyou.Securethe
CrossbarAssembly(A)withOutletBoxScrews(notincluded).
Tightenuntilsnug.
SupplyWireswith
GroundWire
OutletBoxScrews
(notincluded)
OutletBox
A
Figure2
Suggestedrods
forCeilingheight:
8’ceiling:use(1)
12”rod
9’ceiling:use(2)
12”rods
10’ceiling:use(2)
6”rodsand(2)12”
rods
STEP3TestFittingCeilingCanopytoCrossbarAssembly-
A.
tothe
ceiling
RemovemountingballsfromtheCrossbarAssembly(A).Fitthe
CeilingCanopy(D)CrossbarAssembly(A)andsecurewith
mountingballs.Note:Theshouldbesnug
againsttheandthemountingballs.If
CeilingCanopy(D)
not,adjustthelength
ofthenippleontheCrossbarAssembly(A)byunscrewingthe
preassembledhexnutandlockwasherandthenscrewingthe
mountingscrewsinoroutofthecrossbaruntilthecorrectlengthis
achieved.OncetheCeilingCanopy(D)issecure,removethe
mountingballandCeilingCanopy(D)andproceedtoStep4.
MountingScrew
HexNutand
LockWasher
MountingBall
A
D
Figure3
