Pleasegotoforproductcleaningtips.Gototheselection.
Flatheadscrewdriver,Phillipsscrewdriver,pliers,wirecutters,wirestrippers,electricaltape,safetyglasses.
IntegratedLED30W
www.quoizel.comCare+Maintenance
ToolsRequired:
LightSource:
EstimatedAssemblyTime:
Preparation:
20-30minutes
Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagramsbelowtobesureallpartsare
present.Ifanypartsaremissingordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomerserviceforreplacement
parts.
AssemblyInstructionSheet#IS-PCBZ2820C
ForStylePCBZ2820C
1of2
2017QuoizelInc.
ThankyouforpurchasingaQuoizelproduct.
Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-800-645-3184
orvisituson-lineatwww.quoizel.com
WarningsandCautions
Turnoffelectricityatcircuitbreakerormainfuseboxbeforeinstallation.Consultalicensedelectricianifindoubt.
Theseinstructionsareprovidedforyoursafety.Itisveryimportantyoureadthemcompletelybeforeinstallingthefixture.Westrongly
recommendthatalicensed,professionalelectricianperformtheinstallation.
PackageContents
Crossbar
x1
A
C
FixtureBody
x1
MountingScrew
x2
B
D
GlassPanel
x1
STEP1InstallGlassPanel-
A.RemovelockscrewswithrubberwashersfromtheFixtureBody(C).
PlacetheGlassPanel(D)ontotheFixtureBody(C)withcrystal
beadsagainsttheFixtureBody(C).SecuretheGlassPanel(D)by
threadinglockscrewswithrubberwashersbackontotheFixture
Body(C).Handtightenuntilsnug.
E
AllenWrench
x1
Figure1
STEP2AdjusttheFixtureBodyHeight-
A.ByusingtheAllenWrench(E),unscrewthesetscrewonthecable
clasp.Pushthepinonthebottomoftheceilingcanopyandadjust
thecabletoyourdesiredhangingheight.Releaseyourhandonthe
pinandmovethecableclasptothehexnutinsideoftheceiling
canopy.Tightthesetscrewonthecableclaspuntilsnugtoengage
thecable.
B.Movethewireclasptothehexnutinsideoftheceilingcanopy.
Carefullytuckallslackwiresinsideoftheceilingcanopy.
Ceiling
Canopy
SetScrew
CableClasp
HexNut
E
Pin
WireClasp
Figure2
LockScrew
C
D
ReleasedDate:2017-08-31
RubberWasher
