INSTALLATION

Tools:

Adjustable WrenchTeon TapeRags

Model Number: 2MT700, 2AM700

Warnings and Notes:

Check with local plumbing code requirements before installation.

This product should be installed by a local listed plumber.

Do not use plumbers putty on threads.

Installation Steps:

Deck Mount Pot-Filler

(1)Shut off water supply. Remove old faucet.

Clean mounting surface in preparation for new

faucet.

PIONEER INDUSTRIES, INC.

3325 S. Gareld Ave

Commerce, CA 90040

(800) 338-9468

www.pioneerind.com

(2) Do not remove plastic arm bracket before

nish installation to prevent damage on swivel

arms. Be sure to place gasket underneath of

faucet to form watertight seal.

(3) Guide the faucet through mounting hole.

Slide the washer from beneath the mounting

surface. Install the locknut with the help of

mounting tool

(4) Use faucet inlet supply hose to connect

to supply stop. You may need adapter(not

included) if supply stop outlet size is not 3/8”

compression.

(6) Remove the aerator from the spout by

turning counter-clockwise. Turn on supply

stop. Check of any leaks. Make sure all the

connection are secure. Open both handles.

Flush and allow water to run at full ow for at

least one minute. Turn off water. Replace the

aerator.
