Pagina 1/44
© 2017 Phoenix Gold • www.phoenixgold.com
Features CaractéristiquesCaracterísticas:
• All models are full range capable Class-D
Topology
• Monoblocks Master/Slave strappable for
huge power
• Monoblocks Master/Slave linkable for multi-
amp Setups
• Bridgeable channels
• Double tier power supplies with OTM Onboard
Thermal Management
• Remote bass and phase controller with Bass
Shift® (RBPC)
• Switchable balanced or unbalanced inputs
• Auto-turn on circuit (defeatable)
• Tri-lightLEDamplierstatusindicators
• Short circuit, thermal and voltage protection
• Front mount controls and connections
• RCA pass-through outputs on Monoblocks
• RMD ready – Remote monitoring display port
(RMD sold separately)
• Todos los modelos son topología Clase-D de
gama completa
• Monoblocks Maestro/Esclavo con correa para
una Gran Potencia
• Monoblocks Maestro/Esclavo vinculables para
conguracionesdeMulti-Amplicadores
• Canales insertables
• Fuentes de alimentación de dos niveles
• Control remoto de bajos y regulador de fase
con Bass Shift® (RBPC)
• Entradas conmutables balanceadas o no
balanceadas
• Circuito de encendido automático
(desbloqueable)
• Indicadoresdeestadodelamplicadorde
tres luces LED
• Protección contra cortocircuitos, térmicos y
de voltaje
• Controles y conexiones de montaje frontal
• “Pass-through” salidas RCA en Monoblocks
• VMR listo – Puerto de visualización de
monitoreo remoto (El VMR se vende por
separado)
• Tous les modèles ont une topologie de classe
D avec une gamme complète
• Monoblocs originaux/esclaves pouvant être
reliés à un courant puissant
• Monoblocs originaux /esclaves pouvant
être reliés à une installation à plusieurs
amplicateurs
• Pontable à canaux
• Alimentation à deux étages
• Contrôleur de phase et de basse à distance
avec Bass Shift®(RBPC)
• Entrées symétriques ou asymétriques
commutables
• Circuit de mise en marche automatique
(désactivable)
• Voyants DEL à trois lumières de l’état de
l’amplicateur
• Protection thermique et contre les surtensions
et les courts-circuits
• Commandes et raccords à montage frontal
• Sorties intercommunication RCA “pass-
through” en Monoblocs
• Prêt RMD – Port d’écran de contrôle à
distance (RMD vendu séparément)
Models: SX2 400.2, SX2 800.4, SX2 600.1, SX2 1200.1, SX2 1200.6
Amplifier
Manual
Manual del Amplificador
Manuel de l’amplificateur
Amplifier Owner’s Manual
© 2017 Phoenix Gold • www.phoenixgold.com
SX2 400.2 SPECIFICATIONS
RMS Power Ratings listed at less than 1% THD @ 14.4v
Number of Channels: 2
1Ω: N/A
2Ω: 200Wx2
4Ω: 100Wx2
4Ω:Bridged 400Wx1
TotalRMSPower(Sumofratedpower): 400W
Bridgeable: Yes
Crossover Control, Butterworth: FLAT/HP/LP
55Hz - 4kHz @ 12dB/Oct
Includes Remote Bass and
Phase Control (RBPC) with BASS SHIFT
® : N/A
40Hz EQ 0-6dB boost @ 40Hz: N/A
Input Selection: Switchable Balanced/
Unbalanced
300mV-8V Unbalanced
600mV-16V Balanced
Signal Output: N/A
Signal to Noise (@ CEA Standard): 76.5dB
Frequency Response: 10Hz - 39kHz @ +/-3.0dB
Efciency(Average): 88%
SX2 800.4 SPECIFICATIONS
RMS Power Ratings listed at less than 1% THD @ 14.4v
Number of Channels: 4
1Ω: N/A
2Ω: 200Wx4
4Ω: 150Wx4
4Ω:Bridged 400Wx2
TotalRMSPower(Sumofratedpower): 800W
Bridgeable: Yes
Crossover Control, Linkwitz-Riley: FLAT/HP/LP/BP
55Hz - 4kHz @ 12dB/Oct
Includes Remote Bass and
Phase Control (RBPC) with BASS SHIFT
® : Yes
40Hz EQ 0-6dB boost @ 40Hz: N/A
Input Selection: Switchable Balanced/
Unbalanced
300mV-8v Unbalanced
600mV-16v Balanced
Signal Output: N/A
Signal to Noise (@ CEA Standard): 81.4dB
Frequency Response: 10Hz- 39kHz @ +/-3.0dB
Efciency(Average): 88%
IMPORTANT:Apowerbirthcerticateisincludedforeachamplier.SX2ampliersare
conservatively rated and will exceed their RMS power rating shown here. All RMS power
ratingsandmeasurementsareat14.4voltswithnomorethan1%THD.
Auto-Turn On: Yes
Damping Factor: Greater than 250
Topology Class: Class D
Heatsink Type: Extruded Aluminum
Cooling Type: Radiation
Operating Voltage: 11.0V to 16.1V
Switchable Auto-Turn On: Yes
Power Supply Type: Double Tier with OTM
Onboard Thermal Management
Power Terminal: 4 Gauge
Speaker Terminal: 10 Gauge
Recommended Fusing: 40A
Average Current Draw @ 14.4v Music: 9A at 4 ohm
Optional RMD Ready: Yes
Tri-Light Indicators: Blue - Standard Operation
Green-OverVoltageWarning
Thermal Protection
Amber - DC/Short Protection
Red - Internal Fuse Blown
Dimensions(LxWxH): 10.5”x8.5”x2”
267mm x 216mm x 51mm
Auto-Turn On: Yes
Damping Factor: Greater than 200
Topology Class: Class D
Heatsink Type: Extruded Aluminum
Cooling Type: Radiation
Operating Voltage: 11.0V to 16.1V
Switchable Auto-Turn On: Yes
Power Supply Type: Double Tier with OTM
Onboard Thermal Management
Power Terminal: 4 Gauge
Speaker Terminal: 10 Gauge
Recommended Fusing: 50A
Average Current Draw @ 14.4v Music: 16A at 4 ohm
Optional RMD Ready: Yes
Tri-Light Indicators: Blue - Standard Operation
Green-OverVoltageWarning
Thermal Protection
Amber - DC/Short Protection
Red - Internal Fuse Blown
Dimensions(LxWxH): 15.25”x8.5”x2”
387mm x 216mm x 51mm
SPECIFICATIONS
© 2017 Phoenix Gold • www.phoenixgold.com
Amplifier Owner’s Manual
SX2 600.1 SPECIFICATIONS
RMS Power Ratings listed at less than 1% THD @ 14.4v
Number of Channels: 1
1Ω: 600Wx1
2Ω: 450Wx1
4Ω: 300Wx1
TotalRMSPower(Sumofratedpower): 600W
Bridgeable: N/A
Crossover Control, Linkwitz-Riley: HP 10Hz - 120Hz (subsonic)
FLAT/LP 40Hz - 240Hz @ 24dB/Oct
Includes Remote Bass and
Phase Control (RBPC) with BASS SHIFT
® : Yes
40Hz EQ 0-6dB boost @ 40Hz: Yes
Input Selection: Switchable Balanced/
Unbalanced
300mV-8v Unbalanced
600mV-16v Balanced
Signal Output: 2 Channel RCA
Signal to Noise (@ CEA Standard): 85.9dB
Frequency Response: 10Hz - 250Hz @ +/-6.0dB
10Hz -39kHz -3dB LP BYPASSED
Efciency(Average): 85%
SX2 1200.1 SPECIFICATIONS
RMS Power Ratings listed at less than 1% THD @ 14.4v
Number of Channels: 1
1Ω: 1200Wx1
2Ω: 900Wx1
4Ω: 600Wx1
TotalRMSPower(Sumofratedpower): 1200W
Bridgeable: N/A
Crossover Control, Linkwitz-Riley: HP 10Hz - 120Hz (subsonic)
LP 40Hz - 240Hz @ 24dB/Oct
Includes Remote Bass and
Phase Control (RBPC) with BASS SHIFT
® : Yes
40Hz EQ 0-6dB boost @ 40Hz: Yes
Input Selection: Switchable Balanced/
Unbalanced
300mV-8v Unbalanced
600mV-16v Balanced
Signal Output: 2 Channel RCA
Signal to Noise (@ CEA Standard): 86.3dB
Frequency Response: 11Hz - 250Hz @ +/-6.0dB
10Hz -39kHz +/-3dB LP BYPASSED
Efciency(Average): 85%
SX2 1200.6 SPECIFICATIONS
RMS Power Ratings listed at less than 1% THD @ 14.4v
Number of Channels: 6
1Ω: 1-4N/A,5-6250Wx2
2Ω: 200Wx6
4Ω: 150Wx6
Bridged4Ω: 300Wx2
Bridged2Ω: 1-4N/A,5+6500Wx1
TotalRMSPower(Sumofratedpower): 1300W
Bridgeable: Yes
Crossover Control, Linkwitz-Riley: FLAT/HP/LP/BP
55Hz - 4kHz @ 12dB/Oct
Channels 5/6 only: HP 10Hz - 120Hz (subsonic)
LP 45Hz - 1K @ 12dB/Oct
Includes Remote Bass and
Phase Control (RBPC) with BASS SHIFT
® : Yes
40Hz EQ 0-6dB boost @ 40Hz: N/A
Input Selection: Switchable Balanced/
Unbalanced
300mV-8v Unbalanced
600mV-16v Balanced
Signal Output: N/A
Signal to Noise (@ CEA Standard): 81.4dB
Frequency Response: 10Hz- 39kHz @ +/-3.0dB
Efciency(Average): 88%
Auto-Turn On: Yes
Damping Factor: Greater than 200
MASTER/SLAVECapable: Yes-1200Wx1@2ΩStrapped
Topology Class: Class D
Heatsink Type: Extruded Aluminum
Cooling Type: Radiation
Operating Voltage: 11.0V to 16.1V
Switchable Auto-Turn On: Yes
Power Supply Type: Double Tier with OTM
Onboard Thermal Management
Power Terminal: 4 Gauge
Speaker Terminal: 10 Gauge
Recommended Fusing: 60A
Average Current Draw @ 14.4v Music: 15A at 4 ohm
Optional RMD Ready: Yes
Tri-Light Indicators: Blue - Standard Operation
Green-OverVoltageWarning
Thermal Protection
Amber - DC/Short Protection
Red - Internal Fuse Blown
Dimensions(LxWxH): 13.25”x8.5”x2”
337mm x 216mm x 51mm
Auto-Turn On: Yes
Damping Factor: Greater than 200
MASTER/SLAVECapable: Yes-2400Wx1@2ΩStrapped
Topology Class: Class D
Heatsink Type: Extruded Aluminum
Cooling Type: Radiation
Operating Voltage: 11.0V to 16.1V
Switchable Auto-Turn On: Yes
Power Supply Type: Double Tier with OTM
Onboard Thermal Management
Power Terminal: 4 Gauge
Speaker Terminal: 10 Gauge
Recommended Fusing: 80A
Average Current Draw @ 14.4v Music: 26A at 4 ohm
Optional RMD Ready: Yes
Tri-Light Indicators: Blue - Standard Operation
Green-OverVoltageWarning
Thermal Protection
Amber - DC/Short Protection
Red - Internal Fuse Blown
Dimensions(LxWxH): 16.75”x8.5”x2”
425mm x 216mm x 51mm
Auto-Turn On: Yes
Damping Factor: Greater than 200
Topology Class: Class D
Heatsink Type: Extruded Aluminum
Cooling Type: Radiation
Operating Voltage: 11.0V to 16.1V
Switchable Auto-Turn On: Yes
Power Supply Type: Double Tier with OTM
Onboard Thermal Management
Power Terminal: 4 Gauge
Speaker Terminal: 10 Gauge
Recommended Fusing: 70A
Average Current Draw @ 14.4v Music: 24A at 4 ohm
Optional RMD Ready: Yes
Tri-Light Indicators: Blue - Standard Operation
Green-OverVoltageWarning
Thermal Protection
Amber - DC/Short Protection
Red - Internal Fuse Blown
Dimensions(LxWxH): 19.25”x8.5”x2”
489mm x 216mm x 51mm
SPECIFICATIONS
