Models: Z150.2 - Z300.1 - Z300.4 - Z600.5 - Z1000.1
Z-Series
Ampliers
Integrated Cooling Fan - Regulates amplier temperature for sustained performance
High & Low Level Inputs - Versatile connectivity to suit any vehicle (ZRHC High Level Adaptor required) - sold separately
OEM Connection Ready - Compatible with aftermarket or original t source units
High Level Auto-Turn On - Powers on the amplier when an audio signal is supplied (via the ZRHC High Level Adaptor)
Remote Bass Ready - Control the Bass Level with the ZRBC (sold separately)
4-Way Protection Circuit - Thermal / Reversed Power and Speaker Polarity / Low Voltage
Heavy Duty Connector Block - Enables Maximum Current Supply
Ventilateur de refroidissement intégré - Régule la température de l’amplicateur pour une performance soutenue
Entrées haute et basse - Connectivité polyvalente pour tous les véhicules (ZRHC Haut niveau Adaptateur
requis) - vendu séparément
Prêt pour une connexion OEM - Compatible avec les unités d’origine et de rechange.
Mise sous tension automatique à haut niveau - Allume l’amplicateur lorsqu’un signal audio est détecté
(via l’adaptateur ZRHC de haut niveau)
Prêt pour la commande des graves à distance - Contrôle du niveau des graves avec le ZRBC (vendu séparément)
Circuit de protection 4-voies - Puissance thermale/inversée et haut-parleur Polarité/Basse tension.
Bloc de connecteur robuste - Permet une alimentation maximale
Ventilador de Refrigeración Integrado - Regula la temperatura del amplicador para mantener su buen rendimiento
Entradas de Alto y Bajo Nivel - Conectividad versátil para adaptarse a cualquier vehículo (Se requiere de un
Adaptador ZRHC de Alto Nivel) – El mismo se vende por separado
Conexión de OEM Lista - Compatible con unidades originales o de segunda mano.
Encendido Automático de Alto Nivel - Se enciende el amplicador cuando se suministra una señal de audio (A través
del Adaptador de Alto Nivel ZRHC)
Control Remoto de Bajos - Controle el nivel de graves con el ZRBC (se vende por separado)
Circuito de Protección de 4 vías - Potencia térmica / retroceso y altavoz Polaridad / baja tensión.
Bloque de conector robusto - Permite una máxima potencia
Les amplicateurs de la série Z
Los amplicadores series Z
CARACTÉRISTIQUES
FEATURES
CARACTERÍSTICAS
Z-Series Ampliers
© 2017 Phoenix Gold • www.phoenixgold.com
Z300.4 Z150.2 Z300.1 Z600.5 Z1000.1
Class Class A/B Class A/B Class A/B Class A/B Class D
Power (MAX) 1200 Watts 600 Watts 1200 Watts 2400 Watts 2000 Watts
Frequency
Response
20Hz-20KHz 20Hz-20KHz 20Hz-400Hz 20Hz-20KHz 20Hz-300MHz
Dimensions (mm) 312x186x49 232x186x49 312x186x49 372x186x49 312x186x49
RMS Power
Ratings
60W x 4 @ 4ohm
75W x 4 @ 2ohm
150W x 2 @ 4ohm
bridged
60W x 2 @ 4ohm
75W x 2 @ 2ohm
150W x 1 @ 4ohm
bridged
200W x 1 @ 4ohm
300W x 1 @ 2ohm
60W x 4 @ 4ohm
+1 x 200W @ 4ohm
75W x 4 @ 2ohm
+1 x 300W @2ohm
150 x 2 @ 4ohm
bridged
+1 x 300 @ 2ohm
400w p2-x1 @ 4 ohm
700w x 1 @ 2 ohm
1000w x 1 @ 1 ohm
Signal to
Noise Ratio
>50dB >50dB >50dB >50dB >90dB
High & Low Pass
Crossover
12dB per Octave 12dB per Octave 12dB per Octave 12dB per Octave 12dB per Octave
Subsonic Filter N/A N/A 12dB per Octave 12dB per Octave 12dB per Octave
Crossover
Range
50Hz-250Hz 50Hz-250Hz 50Hz-400MHz 50Hz-250Hz (CH1,2,3,4)
50Hz-400Hz (Sub-
woofer)
30Hz to 300Hz
Subsonic
Crossover Range
N/A N/A 10Hz-40Hz 10Hz-40Hz 10Hz to 55Hz
Bass Boost
@ 45Hz
N/A N/A 0 to +18dB 0 to +18dB 0 to +18dB
Low Level
Input Range
0.35 Volts
to 10 Volts
0.35Volts to
10 Volts
0.35 Volts to
10 Volts
0.35 Volts to
10 Volts
200 millivolts to 8 volts
High Level
Input Range
1 Volt to 30 Volts 1 Volt to 30 Volts 1 Volt to 30 Volts 1 Volt to 30 Volts 200 millivolts to 20 volts
Minimum Load
Impedance
2 ohm Stereo &
4 ohm bridged
2 ohm Stereo &
4 ohm bridged
2 ohm 2 ohm Stereo &
4 ohm bridged
1 Ohm
Note:
Phoenix Gold Ampliers have a minimum load impedance
of 2ohm per channel 4ohm bridged
(except Z1000.1 - which is 1 Ohm)
© 2017 Phoenix Gold • www.phoenixgold.com
Z-Series Ampliers
Z150.2 - Z300.1 - Z300.4 - Z600.5 - Z1000.1
Installation Warnings
1. Ensure the +12V lead is disconnected from the battery before you
connect any new equipment
2. Ensure that the amplier mounting location and holes will not interfere
with the petrol tank, brake lines or electrical wiring.
3. Ensure the amplier is securely fastened to the vehicle to prevent the
amplier moving and causing damage in the event of an accident
4. Ensure all wiring is protected from sharp objects and from pinching or
crushing which could result in damage to the audio system
5. Ensure the mounting location has sufcient air ow around the
amplier. If the amplier is mounted in an enclosed space a 3” fan
with ducting should be used to assist with cooling.
6. Do not mount any amplier on a subwoofer enclosure as extended
exposure to vibration may cause damage to the amplier.
7. Ensure the minimum recommended gauge wire/cable or larger for all
amplier connections
8. Appropriate mounting is very important for prolonged life
expectancy of any amplier. Select a location that provides
protection from moisture. Keep in mind that an amplier should never
be mounted upside down. Upside down mounting will compromise
heat dissipation through the heat sink and could engage the thermal
protection circuit.
