Pagina 1/16
Amplifier Manual
Manual del Amplificado r
Manuel del’amplificateur
Models: SX400.1, SX600.1, SX1200.1, SX800.4, SX1200.5
Features: Caractéristiques:
• Compact Size for Easy Installation
• High Eciency Class D Topology
• High and Low Pass Crossovers
• ADAPT Power Management System
(SX800.4, SX1200.5)
• Surface Mount Component Technology
• Direct Insert Power and Speaker Terminals
• Audio Precision Quality Control Verication
• High Temperature Plexiglass cover
• RMD - Remote Monitoring Display Port
• RBCF- Remote subwoofer level control included
(except SX800.4)
• Topologie de classe D de gamme complète
• Petit format pour faciliter l’installation
• Filtres croisés passe-haut et passe-bas
• ADAPT système d’alimentation
(SX800.4, SX1200.5)
• Technologie de composant monté en surface
• Terminaux d’alimentation et de haut-parleurs à
insertion directe
• Vérication du contrôle de la qualité de la précision audio
• Couvercle de plexiglas résistant aux températures élevées
• RMD - Entrée De L’achage de Tension a Distance
• RBCF- Niveau de contrôle de passe-bas inclus (sauf
SX800.4)
Características:
• Tamaño compacto para fácil instalación
• Alta eciencia de clase D Topología
• Crossovers paso alto y bajo
• ADAPT Sistema de Gestión de Energía
(SX800.4, SX1200.5)
• Tecnología “Surface Mount Component”
• Conexiones directas de terminales de poder y de
parlantes
• Control de vericación de calidad de precisión de audio
• Cubierta de Plexiglás resistente a altas temperaturas
• RMD - Puerto de display para monitoreo remoto
• RBCF -Control de nivel de Subwoofer remoto incluido
(excepto SX800.4)
Amplier Owner’s Manual
Phoenix Gold • www.phoenixgold.com
SPECIFICATIONS
SX400.1 SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 300Hz
Signal to Noise Ratio: >90dB
Low Pass Crossover: 12dB per Octave
Subsonic Filter: 12dB per Octave
Low Pass Crossover Range: 30Hz to 300Hz
Subsonic Crossover Range: 10Hz to 55Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 2 ohms
Typical Eciency: 80%
Damping Factor: Greater than 200
Variable Phase Adjustment: 0 to 180 Degrees
RMS Power Output 250w x 1 @ 4 ohms
400w x 1 @ 2 ohms
Power/Ground Wire Size: 8 Gauge
Recommend Power Wire Fuse: 40a
Dimensions (Includes Feet): 7.4” L x 6.9” W x 2.0” H
189mm L x 176mm W x 50mm H
SX600.1 SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 300Hz
Signal to Noise Ratio: >90dB
Low Pass Crossover: 12dB per Octave
Subsonic Filter: 12dB per Octave
Low Pass Crossover Range: 30Hz to 300Hz
Subsonic Crossover Range: 10Hz to 55Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 2 ohms
Typical Eciency: 80%
Damping Factor: Greater than 200
Variable Phase Adjustment: 0 to 180 Degrees
RMS Power Output 400w x 1 @ 2 ohms
600w x 1 @ 1 ohm
Power/Ground Wire Size: 4 Gauge
Recommend Power Wire Fuse: 60a
Dimensions (Includes Feet): 10.1” L x 6.9” W x 2.0” H
256mm L x 176mm W x 50mm H
SX1200.1 SPECIFICATIONS
Frequency Response: ± 1dB from 20Hz to 300Hz
Signal to Noise Ratio: >90dB
Low Pass Crossover: 12dB per Octave
Subsonic Filter: 12dB per Octave
Low Pass Crossover Range: 30Hz to 300Hz
Subsonic Crossover Range: 10Hz to 55Hz
Bass Boost @ 45Hz: 0 to +18dB
Low Level Input Range: 200 millivolts to 8 volts
Lowest Recommend Load: 1 ohm
Typical Eciency: 80%
Damping Factor: Greater than 200
Variable Phase Adjustment: 0 to 180 Degrees
RMS Power Output 800w x 1 @ 2 ohms
1200w x 1 @ 1 ohm
Power/Ground Wire Size: 4 Gauge
Recommend Power Wire Fuse: 120a
Dimensions (Includes Feet): 12.3” L x 6.9” W x 2.0” H
314mm L x 176mm W x 50mm H
IMPORTANT: A power birth certicate is included for each amplier. SX ampliers
are conservatively rated and will exceed their RMS power rating shown here. All
RMS power ratings and measurements are at 14.4 volts with no more than 1% THD.
