Pagina 1/20
www.peavey.com
AQ 12
Enclosure
Operating
Manual
FCC CAUTION:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Any changes or modications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pur-
suant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harm-
ful interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
The equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment,
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
The equipment should be installed and operated with minimum distance 5cm between the radiator and
your body.
IC WARNING:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the fol-
lowing two conditions: (1) this device may not cause interference, and (2) this device must accept any inter-
ference, including interference that may cause undesired operation of the device.
Le prĂ©sent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de
licence. L’exploitation est autorisĂ©e aux deux conditions suivantes : (1) l’appareil ne doit pas produire de
brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioĂ©lectrique subi, mĂȘme si le
brouillage est susceptible d’en compromettre le fonctionnement.
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
the device is compliance with RF exposure guidelines, and the equipment should be installed and operated
with minimum distance 5cm between the radiator and your body.
l’appareil est conforme aux directives d’exposition RF, et l’équipement doit ĂȘtre installĂ© et exploitĂ© avec une
distance minimale de 5 cm entre le radiateur et votre corps.
ENGLISH
ank you for purchasing the Peavey¼ AQℱ12 powered speaker system. e AQℱ12 features a reliable bi-amped power
section that provides a total of 1000 Watts of peak available dynamic power with signal compression to prevent audible
overload. e analog power ampliers and linear power supply are coupled with a DSP based crossover and EQ.
e EQ presets are accessed via a one-knob selector switch. e AQℱ12 provides a balanced input via a combination jack
that accepts balanced TRS 1/4 inch input as well as a balanced XLR input. ere is a balanced ru output via a Male
XLR. ere is an adjustable Level control as well as an LED indicator that lights when the “so-limiting” compression
circuit is activated.
Features
* Two-way bi-amplied analog amp powered speaker system
* 12” heavy-duty woofer
* DXℱ14 compression driver, with 1.4 inch titanium diaphragm
* 670 watts peak dynamic woofer power, 330 watts peak dynamic tweeter power
* BluetoothÂź streaming and pairing are supported
* DSP processing is 56 bit double-precision
* DSP I/O is at 48 kHz and 24 bits, with low-jitter, professional grade components
* Dynamic bass boost function
* Fan cooled for maximum reliability
* Peavey¼ Designed Quadratic roat Waveguideℱ technology, 110 by 80 degree coverage
* Input is via a combo female XLR and 1/4” TRS phone jack with balanced input
OR a Bluetooth Âź signal can be streamed to the speaker system.
* Mic/Line switch to accommodate a wide range of input signals
* ru/Mix output is via a male XLR jack
* Multiple Factory Preset EQ settings for the DSP crossover system
* Rugged plastic injection-molded trapezoidal enclosure
* Cabinet has dual rear corner angled sides for oor monitor use.
* Full-coverage perforated steel grille, with powder coat nish
* Pole mount molded-in for 1 3/8” diameter poles
Applications
e Peavey AQℱ12 has a variety of applications such as sound reinforcement, public address, side ll system, karaoke or
musical playback.
A typical signal source for the line-Gain inputs of the AQℱ12 would be a sound reinforcement mixing console (mixer)
or the output from a CD player, MP3 player or tape deck. A dynamic microphone can be connected directly via the XLR
input and used when the Mic/Line switch in placed into the “Mic” position as well.
e AQℱ12 is a two-way sound reinforcement system based on a heavy-duty 12” woofer and a DXℱ14 titanium diaphragm
dynamic compression driver mounted on a 110 by 80 degree coverage Quadratic roat Waveguideℱ. It’s contemporary
appearance coupled with exceptional performance oer a highly desirable combination.
e light yet durable injection-molded plastic enclosure with molded-in stand mount cup eases portable use for live music
or PA sound. e trapezoidal cabinet has three handles for ease of portability, and two extra angled sections on either side
to allow use as a oor monitor. A full length black powder coated perforated steel grille provides system protection and a
professional appearance.
e heavy-duty 12” woofer has a warm punchy sound for plenty of bass. e DXℱ14 compression driver tweeter is coupled
to a Quadratic roatℱ constant directivity waveguide, an original Peavey¼ design, with smooth, even response, low distor-
tion and good high frequency dispersion.
Advanced Digital Signal Processing (A.D.S.P.) provides the crossover function, driver limiting, as well as the driver EQ to
