1
WARNING: Risk of Fire or Electric Shock
• Disconnect power before installation or any maintenance
of the xture.
• To avoid damage, falling, electric shock or re, do not modify the
xture or replace accessories.
• Only authorized, qualied personnel should install this xture and
should follow the owner’s manual.
• Do not dismantle the xture.
• Do not touch the power supply when the xture is operating.
• For use in environments where an accumulation of non-conductive
dust on the xture may be expected.
• Damp rated. Do not use outdoors.
• Do not mount near gas or electric heaters.
• Do not let power cords touch hot surfaces.
• Equipment should be mounted in locations and at heights where it
will not readily be subjected to tampering by unauthorized personnel.
• The use of accessory equipment is not recommended and may cause
an unsafe condition.
• Do not use this equipment for other than intended use.
IMPORTANT: This product must be installed in accordance with the
applicable installation code by a person familiar with the construction
and operation of the product and the hazards involved.
Models: 67-134, 67-135
Satco Products, Inc.
Brentwood, NY 11717
INSTALLATION AND SAFETY INSTRUCTIONS
IMPORTANT: Read before installing xture. Retain for future reference.
© Copyright 2023 Satco Products, Inc. 3/23 v1.1
INSTALLATION
1. Connect wires to DC 3.6V supply in accordance with local and
national code.
2. Secure xture to Junction Box with hardware provided.
3. Make proper electrical connection, refer to Wiring Diagram, then
push excess wire into Junction Box.
WIRING DIAGRAM
LED REMOTE LAMP HEADS
67-134: Single Head
67-135: Double Head
