1

LED 18" WRAP FIXTURE

WITH DUAL GFCIS

Models: 62-700

INSTALLATION

External Wiring Method

STEP 1: Turn OFF power supply before installation.

STEP 2: Remove diffuser from housing. Near one end of

housing, grasp edge of diffuser and carefully squeeze to

release diffuser from housing. Continue down length of

diffuser to fully disengage.

INSTALLATION AND SAFETY INSTRUCTIONS

IMPORTANT: Read before installing xture. Retain for future reference.

Satco Products, Inc.

Brentwood, NY 11717© Copyright 2024 Satco Products, Inc. 5/24 v2.0

WARNING: Risk of Fire or Electric Shock

• LED xture installation requires knowledge of luminaries’

electrical systems. If not qualied, do not attempt installation.

Contact a qualied electrician.

• To reduce risk of re and over-heating, secure all connections.

• TURN OFF the electrical power before proceeding.

• The electrical rating of this product is 120V 50/60Hz.

• To prevent wiring damage or abrasion, do not expose wiring

to edges of sheet metal or other sharp objects.

• Do not make or alter any open holes in an enclosure of wiring

or electrical components during installation.

• Not intended for recessed installation in ceilings or softs.

• For indoor or damp location.

• This product must be installed in accordance with the owner’s

manual, current electrical codes and/or the current National

Electric Code (NEC).

WARRANTY: This product is guaranteed for a 5-year warranty.

Any quality issue in normal use within the warranty period, will

be repaired or replaced according to the situation and under the

condition specications can be provided. Visit www.Satco.com

for full warranty details and dimmer compatibility information.

PartDescriptionQuantity

LED Module1

GFCI Socket1

Modulator Body1

Machine Screw2

Drywall Anchor2

Wood Screw2

Wire Nuts3

5CCT Switch1

LED Driver1

18" L x 2 1/5" W x 4 7/16" D

(458mm) x (64mm) x (113mm)

STEP 3: Remove xture components and parts.

Check that all parts are included.

STEP 4: Thread two machine screws into junction

box (NOTE: screws must be the same distance apart

as keyholes in back of housing assembly).
