THE XPR-5572R IS APPROVED FOR USE

WARNINGS - INTRINSICALLY SAFE

yWARNING: Use only the approved Nightstick 5572-BATT Lithium-ion

rechargeable battery pack or the approved non-rechargeable batteries

listed below.

yWARNING: To prevent ignition of a hazardous atmosphere, do not open

the battery compartment or attempt to exchange any of the supplied battery

packs while in the hazardous environment. This task must ONLY be

performed in an area known to be non-hazardous.

yWARNING: To prevent ignition of a hazardous atmosphere, the approved

Nightstick 5572-BATT Lithium-ion rechargeable battery pack must only be

charged in an area known to be non-hazardous.

yWARNING: When using non-rechargeable batteries in the Nightstick

5570-BATT, use only Energizer EN91 or Energizer E91 batteries.

yWARNING: To prevent ignition of a hazardous atmosphere, non-

rechargeable AA batteries must only be changed in an area known to be

non-hazardous.

yWARNING: To reduce the risk of explosion, do not mix new non-

rechargeable batteries with used non-rechargeable batteries, or mix non-

rechargeable batteries from different manufacturers.

yWARNING: Substitution of components may impair intrinsic safety.

SPECIAL INSTRUCTIONS FOR INTRINSIC SAFETY

yFor personal safety, always conrm the rating of any known hazardous or

potentially hazardous location where the Angle Light is to be used.

CAUTION

yRechargeable Lithium-ion batteries must be used and charged properly.

Improper use can result in serious injury, re, or death.

yDo not leave the battery in direct sunlight or use or store the battery inside

cars in hot weather.

yDo not expose the battery to water or salt water, or allow the battery to

get wet.

yDo not store the battery with metallic objects that may cause a short circuit.

yImmediately discontinue use of the battery if the battery emits an unusual

smell, feels hot, changes color, changes shape or appears abnormal in any

way.

yKeep out of the reach of children.

MOUNTING THE CHARGER

WARNING: While the XPR-5572 Angle Light is certied as an

Intrinsically Safe Permissible product, the charger is NOT Intrinsically

Safe. The charger MUST be installed in a location far enough outside of

the hazardous environment to ensure that it can never come in contact

with any potentially explosive materials.

Tools required for installation:

yA small level

yA hammer

yA small center punch or nail

yAn electric drill and drill bits to suit the wall material and anchoring method

yA #2 Phillips Head Screwdriver

yTorx Wrench (included)

The Nightstick 5572-CHGR1 wall/vehicle charger is designed to mount to

any at, dry surface. The design of the charger will secure the Angle Light

into the charger at virtually any angle. As such, the charger can be mounted

at any angle. For purposes of these instructions, we will be mounting the

charger vertically.

Included with the wall/vehicle charger are 4 - #8 x 32 x 1 ½” Pan Head

Screws that can be used to install the charger to virtually any surface however

special mounting requirements may require different hardware.

yTo install the charger, use the full-size DRILLING DIAGRAM TEMPLATE

located here in the instructions.

ySelect a location to install the charger making sure to check what is on

the other side of the mounting surface…no electrical wires, water lines, etc.

yThe other consideration for determining the mounting location of the

charger is the distance to the AC wall outlet or the 12v DC power outlet.

Please check to make sure that the appropriate Nightstick AC or DC Power

Supply will reach the charger when it is plugged in. Otherwise, relocate the

charger’s installation location as needed.

yOnce the appropriate location has been selected, tape the template in

place using blue painter’s tape (or other non-marring tape) ensuring that

the template is level.

Bayco Products, Inc. • 640 South Sanden Blvd. • Wylie, TX 75098 • 1-800-233-2155 • 1-469-326-9400 • www.mynightstick.com

INS-XPR5572-16

Included in the box - Compris dans la boîte - Incluido en la caja

Instruction Manual

XPR-5572

THANK YOU FOR SELECTING THE NIGHTSTICK XPR-5572

INTRINSICALLY SAFE PERMISSIBLE RECHARGEABLE ANGLE LIGHT!

PLEASE SAVE THESE INSTRUCTIONS

Please read these instructions before using your Nightstick XPR-5572

Intrinsically Safe Permissible Rechargeable Angle Light. They include

important safety information and operating instructions.

Permissible Nightstick XPR-5572 Flashlight/Floodlight

APPROVAL No. 20-A150005-0

TESTED FOR INTRINSIC SAFETY IN METHANE-AIR MIXTURES ONLY

WARNINGS: Do not charge in hazardous location. MSHA approved for use with Bayco

Li-ion Battery Pack 5572-BATT or Primary 5570-BATT Battery Pack containing 6 AA

Energizer Type EN91 or L91 batteries. Replace the Battery Pack in fresh air only. Do not

mix batteries from different manufacturers or different types. Battery Pack to be replaced by

a qualified technician only. The Model Nightstick 5572 must not be opened in areas where

permissibility is required. Substitution of components may impair Intrinsic Safety.

CLASS I DIV I GRPS A-D T3

CLASS II & III DIV I GRPS E-G

CLASS I ZONE 0 Group IIC T3

CLASS II ZONE 20 Group IIIC T3

-20ºC ≤ Tamb ≤ +70ºC

0359

E 467756

Ex ia FLASHLIGHT FOR USE IN HAZARDOUS LOCATIONS

UL listed for use with Bayco Li-ion Battery Pack

5572-BATT or Primary 5570-BATT Battery Pack

containing 6 AA Energizer Type EN91 or E91 batteries.
