Bayco Products, Inc. • 640 South Sanden Blvd. • Wylie, TX 75098 • 1-800-233-2155 • 1-469-326-9400 • www.nightstick.com

INS-XPR-5568-DL-24

08-30-2024

CAUTION

yRechargeable Lithium-ion batteries must be used and charged properly. Improper

use can result in serious injury, re, or death.

yDo not leave the battery in direct sunlight or use or store the battery inside cars in

hot weather.

yDo not expose the battery to water or salt water, or allow the battery to get wet.

yDo not store the battery with metallic objects that may cause a short circuit.

yImmediately discontinue use of the battery if the battery emits an unusual smell, feels hot,

changes color, changes shape or appears abnormal in any way.

yKeep out of the reach of children.

STROBE WARNING

Exposure to strobing lights may cause dizziness, disorientation, and nausea. A very

small percentage of people suffer from photosensitive epilepsy and may experience

seizures or blackouts triggered by strobing lights. For more information from the

EPILEPSY FOUNDATION about photosensitivity and seizures, please visit www.

epilepsy.com. Anyone who has had symptoms linked to this condition should consult a

doctor before using this product.

MOUNTING THE CHARGER

CHARGER INPUT: 12 / 24 VDC

WARNING: While the XPR-5568 Angle Light is certied as an intrinsically safe

product, the charger is NOT intrinsically safe. The charger MUST be installed in

a location far enough outside of the hazardous environment to ensure that it can

never come in contact with any potentially explosive materials.

Tools required for installation:

ySmall level

yHammer

ySmall center punch or nail

yElectric drill and drill bits to suit the wall material and anchoring method

y#2 Phillips screwdriver

The Nightstick wall/vehicle charger is designed to mount to any at, dry surface. The

design of the charger will secure the angle light into the charger at any angle and the charger

can be mounted at any angle. These instructions are for mounting the charger vertically.

Four (4) Pan Head screws (included) can be used to install the charger to most

surfaces, however special hardware may be needed for some situations.

ySelect a location to install the charger. Check that there are no electrical wires, water

lines, etc. on the other side of the mounting surface.

yCheck the distance to the AC wall outlet or the 10v DC power outlet to make sure

the AC or DC power supply will reach the charger when it is plugged in. Relocate the

charger’s location as needed.

yOnce the location has been selected, use a hammer and a small center punch or nail

to mark all 4 of the hole locations.

yIf the charger is being installed onto drywall, you will need to install 4 - Drywall Anchors

(included). Use a drill bit to drill 4 holes through the drywall in the locations of the nail

marks. Use a Phillips screwdriver to install all 4 drywall anchors into the wall until they are

ush with the surface.

METAL SURFACE: If the charger is being installed onto a metal surface, drill 4

appropriately sized holes. The diameter of the drill bit required will be determined

by the type of metal and the thickness of the material.

WOOD SURFACE: If the charger is being installed onto a wooden surface, drill a

pilot hole in all 4 locations.

yThe mounting screw holes can be accessed from the top of the charger when the light

is not installed in the charger.

yLine up the mounting holes for the charger with the pilot holes (or drywall anchors) and

carefully insert each of the supplied Pan Head screws into the mounting holes from the

front of the charger. Give each screw a small turn by hand to get each one started.

yHand-tighten each screw with a screwdriver until the charger is securely afxed to

the mounting surface. CAUTION: Do not use an electric drill or drill driver to install the

screws. Do not over-tighten because it could damage the mounting holes in the charger.

yPlug either the AC or DC power supply cord into the power port on the bottom of the

charger and then into the appropriate power outlet.

yThe LED charge indicator light on the charger will momentarily light up GREEN, then

turn RED and then turn off. This is normal behavior when the angle light is not installed

in the charger.

yThe charger is now ready to use.

POWERING THE XPR-5568

The XPR-5568 Intrinsically Safe Rechargeable Angle Light can be powered in one

of two ways:

yThe Nightstick 5568-BATT Lithium-ion Rechargeable Battery Pack.

yThe Nightstick 5566-CARRIER Non-Rechargeable Battery Carrier and 3 - AA

Energizer EN91 or Energizer E91 Batteries.

WARNING: Do not use any other type of non-rechargeable battery with this light.

WARNING: Do not use rechargeable AA batteries with this light.

Instruction Manual

Intrant

®

XPR-5568GX/RX

US PATENT 9,713,217 & 10,119,663

THE XPR-5568 IS APPROVED FOR USE

CLASS I DIV 1 GRPS A-D T4

CLASS II & III DIV1 GRPS E-G T135°C

CLASS I ZONE 0 AEx ia IIC T4 Ga

Ex ia op is I Ma

Ex ia op is IIC T4 Ga

DEMKO 17 ATEX 1927

UL22UKEX2426

IECEx UL 17.0082

-20ºC ≤ Tamb ≤ +40ºC

1.5V/Cell Alkaline

3.7V/Cell Li-ion

IP-67

Um: 10V

I M1 Ex ia op is I Ma

II 1 G Ex ia op is IIC T4 Ga

Bayco Products, Inc. XPR-5568GX

Ex ia FLASHLIGHT FOR USE IN HAZARDOUS LOCATIONS

For use with Bayco Li-ion Battery Pack 5568-BATT or

5566-CARRIER with 3 AA Energizer Type EN91 or E91

batteries only

640 S. Sanden Blvd., Wylie, TX 75098

INTRINSICALLY SAFE

SECURITE INTRINSEQUE

E 467756

ELECTRICAL SAFETY

ID 4003544

Control Drawing: 5568-CERT-DWG1-03For Battery Charger Connection see Instruction

Manual Drawing: 5562-68-MECH-DWG1-09

2575

0359

22-AV4BO-0250X

Ex ia op is I Ma

Ex ia op is IIC T4 Ga

(-20ºC ≤ Tamb ≤ +40ºC)

NCC 18.0110 X

ATENÇÃO – UTILIZAR SOMENTE BATERIAS ENERGIZER E91 OU EN91.

ATENÇÃO – NÃO SUBSTITUIR A BATERIA QUANDO UMA ATMOSFERA

EXPLOSIVA ESTIVER PRESENTE.

ATENÇÃO – NÃO RECARREGUE A BATERIA EM ÁREA CLASSIFICADA.

CLASS I DIV 1 GRPS A-D T4

CLASS II & III DIV1 GRPS E-G T135°C

CLASS I ZONE 0 AEx ia IIC T4 Ga

Ex ia op is I Ma

Ex ia op is IIC T4 Ga

DEMKO 17 ATEX 1927

UL22UKEX2426

IECEx UL 17.0082

-20ºC ≤ Tamb ≤ +40ºC

1.5V/Cell Alkaline

3.7V/Cell Li-ion

IP-67

Um: 10V

I M1 Ex ia op is I Ma

II 1 G Ex ia op is IIC T4 Ga

Bayco Products, Inc. XPR-5568RX

Ex ia FLASHLIGHT FOR USE IN HAZARDOUS LOCATIONS

For use with Bayco Li-ion Battery Pack 5568-BATT or

5566-CARRIER with 3 AA Energizer Type EN91 or E91

batteries only

640 S. Sanden Blvd., Wylie, TX 75098

INTRINSICALLY SAFE

SECURITE INTRINSEQUE

E 467756

ELECTRICAL SAFETY

ID 4003544

Control Drawing: 5568-CERT-DWG1-03For Battery Charger Connection see Instruction

Manual Drawing: 5562-68-MECH-DWG1-09

2575

0359

22-AV4BO-0250X

Ex ia op is I Ma

Ex ia op is IIC T4 Ga

(-20ºC ≤ Tamb ≤ +40ºC)

NCC 18.0110 X

ATENÇÃO – UTILIZAR SOMENTE BATERIAS ENERGIZER E91 OU EN91.

ATENÇÃO – NÃO SUBSTITUIR A BATERIA QUANDO UMA ATMOSFERA

EXPLOSIVA ESTIVER PRESENTE.

ATENÇÃO – NÃO RECARREGUE A BATERIA EM ÁREA CLASSIFICADA.

WARNINGS - INTRINSICALLY SAFE

yWARNING: Use only the approved Nightstick 5568-BATT Lithium-ion rechargeable

battery pack or the approved non-rechargeable batteries listed in special condition of

use in bullet 4.

yWARNING: To prevent ignition of a hazardous atmosphere, do not open any part

or attempt to exchange any of the supplied battery packs while in the hazardous

environment. This task must ONLY be performed in an area known to be non-hazardous.

yWARNING: To prevent ignition of a hazardous atmosphere, the approved Nightstick

5568-BATT Lithium-ion rechargeable battery pack must only be charged in an area

known to be non-hazardous.

yWARNING: When using non-rechargeable batteries in the Nightstick 5566-CARRIER,

use only Energizer EN91 or Energizer E91 batteries.

yWARNING: To prevent ignition of a hazardous atmosphere, non-rechargeable AA

batteries must only be changed in an area known to be non-hazardous.

yWARNING: To reduce the risk of explosion, do not mix new non-rechargeable

batteries with used non-rechargeable batteries, or mix non-rechargeable batteries from

different manufacturers.

yWARNING: Substitution of components may impair intrinsic safety.

yWARNING: This equipment could be susceptible to electrostatic charge as it

measured capacitance of 4 pF from external metal parts to earth.

SPECIAL INSTRUCTIONS FOR INTRINSIC SAFETY

yFor personal safety, always conrm the rating of any known hazardous or potentially

hazardous location where the Angle Light is to be used.

yOnly devices directly connected to apparatus complying with the IEC 60950 series

are allowed.
