Bayco Products, Inc. • 640 South Sanden Blvd. • Wylie, TX 75098 • 1-800-233-2155 • 1-469-326-9400 • www.nightstick.com

INS-TWM-852XLG2-19

BEFORE ATTACHING, INSPECTING OR SERVICING THE TWM

yEngage the safety on the rearm (if applicable).

yRemove the magazine from the rearm (if applicable).

yOpen the action and visually and physically inspect the chamber to be sure it is empty.

yKeep the barrel pointed in a safe direction at all times and never place your hand in

front of the muzzle.

WARNING: IT IS IMPERATIVE THAT SAFETY MEASURES BE EMPLOYED AT ALL

TIMES WHILE HANDLING A FIREARM.

GENERAL SAFETY WARNINGS

yNOT FOR USE ABOVE HAZARDOUS LOCATIONS

yDO NOT use in explosive atmospheres, near ammable liquids, or where explosion

proof lamps are required.

yDO NOT use in the proximity of vehicles or equipment when there is a risk of

ammable liquids coming into contact with the ashlight.

yDO NOT expose the batteries to water or salt water, or allow the batteries to get wet.

yDO NOT store the batteries with metallic objects that may cause a short circuit.

yImmediately discontinue use of the batteries if they emit an unusual smell, feel hot,

change color, change shape or appear abnormal in any way.

yKeep out of the reach of children.

INSTALL BATTERIES

Image 1

Image 2

Image 3

yOpen the Battery Door Screw using a Phillips head screwdriver. (Image 1)

yInsert the included CR123 Batteries using the battery orientation markings on the

side of the light. (Image 2)

yRe-install the Battery Door Screw until fully tightened. (Image 3)

INSTALL THE LIGHT ONTO YOUR FIREARM

The TWM is designed to be easily attached and detached from the rearm’s tactical

rail. The rearm must have a tactical rail and it must have at least one cross rail slot. The

TWM is not designed to be used on a rearm that does not have a cross rail slot.

IMPORTANT: Your TWM comes pre-congured with the L2 modular channel-

locking insert. If the t is not correct for your specic handgun model, use the

Allen wrench to switch to the L1 insert.

Image 4

Image 5Image 6

yPush inward on the head of the rail clamp tension thumbscrew to fully open the

adjustable portion of the rail clamp. (Image 4)

yWhile making sure that your rearm is in a safe condition and that the barrel is pointed

in a safe direction, place the xed portion of the rail clamp into the groove of the tactical

rail on your rearm and align the insert tab with the slot on your rearm.

yRotate the TWM onto the tactical rail (Image 5). Release the pressure on the tension

thumbscrew making sure that the TWM is gripping both sides of the tactical rail of your

rearm. Verify that the insert tab is fully seated into the rail slot of the rearm. (Image 6)

Instruction Manual

TWM-852XL

Please read these instructions before using your Nightstick TWM-852XL. They

include important assembly and operating instructions.

PACKAGE CONTENTS

y1 - Weapon Mounted Light – Long Gun Single Switch

y2 - CR123 Lithium Batteries

y2 - Inserts L1 and L2 (L2 is pre-installed)

y2 - Cross Rail Mounting Cap Head Screws (1 pre-installed & 1 spare)

y1 - Allen Wrench

WEAPON SAFETY

PLEASE BE SURE TO READ, UNDERSTAND AND FOLLOW THESE SAFETY

AND OPERATING INSTRUCTIONS WHEN HANDLING A FIREARM OR THE

NIGHTSTICK TWM WHEN MOUNTED ON A FIREARM. FAILURE TO DO SO CAN

BE DANGEROUS AND COULD RESULT IN SERIOUS INJURY, DAMAGE TO

PROPERTY, OR DEATH.

Use of a rearm under any circumstance is inherently dangerous. SERIOUS

INJURY OR EVEN DEATH may result without proper training in the safe handling of

rearms. Proper training should be obtained from an accredited rearms safety program

conducted by a qualied instructor.

Read, understand and follow all of the safety instructions that came with your rearm

before attaching your new TWM.

yAlways assume every rearm is loaded and treat that rearm as such.

yNever point a rearm at anything that you are not willing to destroy.

yNever service your rearm or your TWM when mounted on a rearm without rst

activating the weapon’s safety (if applicable), removing the magazine, opening the

action and physically and visually inspecting to make sure that no ammunition is

installed in the rearm.

WEAPON MOUNTED LIGHT SAFETY

yNightstick recommends that the TWM should only be activated with the non-trigger

hand (support hand) while employing a two-hand grip on the rearm and with the

trigger nger fully outside the trigger guard when applicable.

WARNING: FAILURE TO DO SO COULD RESULT IN AN ACCIDENTAL DISCHARGE

AND SERIOUS INJURY, DAMAGE TO PROPERTY, OR DEATH.

yThoroughly practice (employing safe training conditions) with the TWM and an

unloaded rearm before using the weapon.
