The new SECURE LOCK feature of the

NL4MM adapter enables to double lock

the speakON NL4FX or NL4FC cable

connector on one side.

CONNECTING:

The NL4MM LOCKING RING has to be on

the back position as shown.

( UNLOCKED = visible)

Insert the cable connector NL4FX or

NL4FC 1 and turn clockwise

st

2 to lock (1 lock).

Slide the NL4MM ring to the LOCK

nd

position (2 lock).

RELEASE:

Slide the NL4MM ring to UNLOCK

position.

To separate the speakON cable

connector:

Pull latch 1 and

turn counterclockwise 2 .

A

A

B

B

C

A

B

C

USE THIS SIDE FOR

SECU

R

E C

ON

NECTION

SLIDE RING

UNLOCKLOCK

U

N

L

O

C

K

E

D

A

B

1.

2.

NL4MMX

|

speak AdapterON

®

R

®

Attention: speak is not to be used as an AC mains or power supply connector!ON

OPERATING INSTRUCTION

Draft. Nr.: BDA 112 V2 Update: 2019-10-29
