A ASSEMBLY INFORMATION

Draft. Nr.: BDA 589 V1Update: 2020-05-20 Data subject to change without prior notice. 2020 NEUTRIK . ALL RIGHTS RESERVED. NEUTRIK are registered trademark.

II

®®

©

www.neutrik.com

R

R

ATTENTION:

®

speak is NOT to be used as an mains or power supply connector!ON

WIRINGCONNECTION

https://www.neutrik.com/products/audio/speakon

®

speakChassis ConnectorON

NL2MPXX

ASSEMBLY INSTRUCTION

PANEL CUTOUT (Rear Side)

NL2MPXX

®

Flat tabs for 3/16" FASTON

4.85 [0.187" x 0.020"] mm x 0. mm

1+

1-

123

NeutrikAG LI T: +423/2372424 F:+423/232 53 93

NeutrikUSA Inc. USA T:+1704/972 3050 F:+1704/438 9202

()

Neutrik UK Ltd. UK T:+441983/811441 F:+441983/811439

Neutrik VertriebsGmbHDE/NL/AT/DK T:+498131/280890 F:+498131/280830

Neutrik France FR T:+33 1/4131 6750 F:+33 1/4131 0511

Neutrik Tokyo Ltd. JP T:+81 3/3663 4733 F:+81 3/3663 4796

Neutrik Hong KongLtd.HK T:+852/2687 6055 F:+852/2687 6052

Neutrik India Pvt. Ltd. INDT:+91/982 05 43 424 F:+91/22 26163 540

[]

≥Ø 24.0 .945

±0.1±0.003

[]

19.0 .748

[]≥Ø 3.2 .126

±0.1±0.003

[]24.0 .945

ATTENTION

Maximum allowable torque M

A

Front assemblyRear assembly

90 Ncm60 Ncm

NL2MPXX

Countersunk thru holes for

countersunk machine screws

(e.g.: M3, 4-40; screws not included)

(screws not included)

B More Information on the www.neutrik.com

MOUNTING
