Your SCM 960 microphone was carefully packed at the factory, and the shipping carton (or carrying case) was designed to

protect the unit during shipping. Please retain this container for subsequent transport and in the highly unlikely event that you

ever need to return your microphone for servicing. The optional SMCC-2 aluminum carrying case is highly recommended for the

most convenient and safe transport or permanent storage. It has roomy compartments for your SCM 960 microphone and all

available accessories, plus XLR cables.

Congratulations on purchasing a Nady SCM 960 Condenser Microphone. These superior microphone is perfect for

recording studio vocals, acoustic instruments, orchestras and choral groups, ambient instrument audio, and many

live sound applications. Powerful and versatile, the SCM 960 microphone meets the stringent requirements of even

the most demanding digital recording and live broadcasting applications.

UNPACKING, INSPECTION, STORAGE AND TRANSPORT

SCM 960 microphone

User guide

Warranty card

48V phantom power supply (SMPS-1)

Aluminum flight case (SMCC-2)

Shockmount (SSM-3)

Foam windscreen (FW-1)

The SCM 960 offers transformerless output and true condenser design (element constantly biased by the pre-amp) for exception-

ally low self noise and increased dynamic range, enhanced low and high end response with improved linearity across the

frequency range and maximum SPL capacity. It features a large diaphragm capsule (1 inch), three-way pad switch with 0dB,

10dB and 20dB of attenuation, and two selectable polar patterns: omni and cardioid. The SCM 960 uses a carefully selected

Field Effect Transistor (FET), specially chosen for its low distortion and superior signal-to-noise ratio.

(Note: For optimum performance, it is best to let the microphone warm up for 5 to 10 minutes)

The SCM 960 is manufactured with the finest materials and features a machined housing with advanced internal shock mount

construction for the highest structural integrity and rugged reliability. It requires 48V phantom power to operate, typically

supplied by the microphone pre-amplifier or mixing console. The optional Nady SMPS-1 phantom power supply can also be

used.

STANDARD ITEMS SUPPLIED

OPTIONAL ACCESSORIES

FEATURES

This guide covers the operation of the SCM 960 microphone and the available optional accessories.

To take full advantage of the superb features of your microphone, and to enjoy long and trouble-free use, please

read this user's guide carefully.

NADY SCM 960

USER GUIDE
