PD-96XXGC/PD-95XXGC

Multiport Series User Guide

Introduction

Microchip’s family of Power over Ethernet Midspans (PoE) PD-96XXGC/AC and PD-95XXGC/AC inject power over

data-carrying Ethernet cabling. Employing these devices reduces the need for AC outlets, local UPS, and AC/DC

adapters near Powered Devices (PDs).

PD-9x06GC, PD-9x12GC, and PD-9x24GC/AC Midspans support 6, 12, and 24 ports respectively, in a

10/100/1000BaseTx Ethernet network, over TIA/EIA-568 category 5/5e/6 cabling. PD-96xxGC and PD-95xxGC

family devices can provide up to 90 W and 60 W respectively according to the new IEEE

® 802.3bt standards. DC

power is supplied over both spare and data pairs of wires within a cable (1/2, 3/6, 4/5, and 7/8) to terminal units.

PoE Midspan normally powers devices that are PoE enabled or are equipped to receive power over Ethernet. These

devices are called Powered Devices (PDs).

PoE Midspans offer the following important features.

•Safe and reliable power over an existing Ethernet infrastructure.

•Remote management using web control and/or SNMPv3.

•High-level of network security.

•Safe solution that protects network infrastructure.

•Standards compliant: IEEE 802.3bt.

•Provides safe Power and Data over a single RJ45 cable.

© 2021 Microchip Technology Inc.

and its subsidiaries

User GuideDS00004094A-page 1
