User Guide

© 2023 Microchip Technology Inc. and its subsidiaries

DS50003625A - 1

Introducon (Ask a Queson)

When creating a design using an IGLOO2 device, if you use any of the two DDR controllers (FDDR or MDDR)

or Serial High speed controller (SERDESIF) blocks, you must initialize the conguration registers of these blocks

at run-time before they can be used. For example, for the DDR controller, you must set the DDR mode (DDR3/

DDR2/LPDDR), PHY width, burst mode and ECC. Similarly, for the SERDESIF block used as a PCIe endpoint, you

must set the PCIE BAR to AXI (or AHB) window.

In this document, we describe all the steps necessary to create a Libero design that automatically initializes the

DDR controller and SERDESIF blocks at power up, with the Standalone Initialization mode ON.

First we provide a detailed description of the theory of operation. We introduce the major components of the

Peripheral Initialization Solution and outline how they interact.

Unlike the normal ow (Standalone Initialization OFF) where the initialization solution is created by the System

Builder, in the case of Standalone Initialization mode ON, the initialization solution has to be put together in

SmartDesign using dierent soft IP cores (mentioned in the latter sections), whether you choose to use System

Builder or not. System Builder will not create any initialization logic for any of the peripherals. You have to build

the initialization logic that sits outside the System Builder block, should you choose to use System Builder at all.

Note that as the name suggests, the standalone initialization logic has to be built separately for each of the

peripherals (DDR/SERDES) used.

Next, we describe how to build designs with the Standalone Initialization mode ON in cases where you choose

to use System Builder and in cases where you choose not to.

In this section we address:

•The creation of the conguration data for DDR controller and SERDESIF conguration registers

•The creation of the FPGA logic required to transfer the conguration data to the dierent ASIC conguration

registers

For complete details about the DDR controller and SERDESIF conguration registers please refer to the UG0447:

SmartFusion2 and IGLOO2 FPGA High-Speed Serial Interfaces User Guide and UG0446: SmartFusion2 and

IGLOO2 FPGA High Speed DDR Interfaces User Guide.

IGLOO2 Standalone Peripheral Inializaon Methodology

User Guide
